Access Power Controller Terminal Identification:

Terminal Legend
– Power +
– Control +
TRIGGER
INPUT 1-INPUT 8
IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO

Power Supply Board Stand-by Battery Specifications:

Battery Maximal11FDV
7AH 30 Mins./4A
12AH 35 Mins./4A
40AH Over 4 Hours/4A
65AH Over 4 Hours/4A
*Only these configurations can be utilized in Canadian installations.
- 8 -
Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
These terminals are paralleled to the [– Control +] terminals.
These terminals are paralleled to the [– Power +] terminals.
These terminals can be connected to an external Listed power-limited access control
power supply to provide isolated operating power for the devices (Not evaluated by UL).
Jumpers J1 and J2 must be removed.
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir's, etc.)
12VDC to 24VDC trigger controlled outputs. Maximum load per output is 2.5A.
Maximal11FDV: P/S 1 - 9.8-13.2VDC @ 3.3A P/S 2 - 9.8-13.2VDC @ 3.3A or
P/S 1 - 19.9-26.4VDC @ 3.6A P/S 2 - 19.9-26.4VDC @ 3.6A or
P/S 1 - 9.8-13.2VDC @ 3.3A and P/S 2 - 19.9-26.4VDC @ 3.6A.
Maximal33FDV: P/S 1 - 9.7-13.2VDC @ 5.3A P/S 2 - 9.7-13.2VDC @ 5.3A or
P/S 1 - 19.8-26.4VDC @ 5.6A P/S 2 - 19.8-26.4VDC @ 5.6A or
P/S 1 - 9.7-13.2VDC @ 5.3A and P/S 2 - 19.8-26.4VDC @ 5.6A.
Maximal55FDV: P/S 1 - 9.7-13.2VDC @ 9.3A and P/S 2 - 9.7-13.2VDC @ 9.3A.
Maximal75FDV: P/S 1 - 9.7-13.2VDC @ 9.3A and P/S 2 - 19.8-26.4VDC @ 9.6A.
Maximal77FDV: P/S 1 - 19.8-26.4VDC @ 9.6A and P/S 2 - 19.8-26.4VDC @ 9.6A.
Fail-Safe [NC positive (+) & COM Negative (–)], Fail-Secure [NO positive (+) &
COM Negative (–)], Auxiliary output [C positive (+) & COM Negative (–)].
When using AC power supplies polarity needs not to be observed.
Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 5-9, pg. 12).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting.
Maximal33FDV
10 Mins./6A
30 Mins./6A
Over 4 Hours/6A
Over 4 Hours/6A
Maximal11FDV / Maximal33FDV / Maximal55FDV / Maximal77FDV / Maximal75FDV Access Power Controllers (PTC)
Maximal55FDV, Maximal75FDV and
Maximal77FDV
5 Mins./10A
30 Mins./10A
Over 2 Hours/10A
Over 4 Hours/10A
