Access Power Controller Terminal Identification; Power Supply Board Stand-By Battery Specifications; Power Supply Board Output Voltage Settings - Altronix Maximal FDV Series Installation Manual

Power Supply Board Terminal Identification:
Terminal Legend
L, N
+ DC –
Trigger EOL
Supervised
NO, GND RESET
+ AUX –
AC FAIL
NC, C, NO
BAT FAIL
NC, C, NO
+ BAT –

Access Power Controller Terminal Identification:

Terminal Legend
– Power +
– Control +
TRIGGER INPUT1 -
INPUT 8 IN, GND
OUTPUT 1-
OUTPUT 8
NC, C, NO, COM
FACP INTERFACE
T, + INPUT –
FACP INTERFACE
NC, C, NO

Power Supply Board Stand-by Battery Specifications:

Battery Maximal3FDV
7AH
12AH
40AH
Over 4 Hours/6A
65AH
Over 4 Hours/6A
Maximal3FDV/5FDV/7FDV Series (PTC) Installation Guide
Function/Description
Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral.
Do not use terminal marked [G]
Factory connected to ACM8 board.
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally
open, normally closed from an FACP output circuit (Fig. 3, pg. 9).
FACP interface latching or non-latching (Fig. 3, pg. 9).
Auxiliary output rated @ 1A (unswitched) (Fig. 3, pg. 9).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (Fig. 3, pg. 9).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (Fig. 3, pg. 9).
Stand-by battery connections.
Maximum charge current 1.54A (Fig. 3, pg. 9).
Function/Description
12VDC or 24VDC from power supply/charger (factory connected).
These terminals are paralleled to the [– Control +] terminals.
These terminals are paralleled to the [– Power +] terminals.
These terminals can be connected to an external access control power supply to provide
isolated operating power for the devices. Jumpers J1 and J2 must be removed.
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit PIRs, etc.)
12VDC to 24VDC trigger controlled outputs are rated at 2.5A.
Maximal3FDV - 10.0-13.2VDC @ 4.6A or 20.19-26.4VDC @ 5.2A.
Maximal5FDV - 10.03-13.2VDC @ 8.6A.
Maximal7FDV - 20.17-26.4VDC @ 9.2A.
Fail-Safe [NC positive (+) & COM Negative (–)], Fail-Secure [NO positive (+) &
COM Negative (–)], Auxiliary output [C positive (+) & COM Negative (–)].
When using AC power supplies polarity needs not to be observed.
Contacts shown in a non-triggered state.
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP signaling circuit output (Figs. 5-9, pg. 11).
Form "C" relay contact rated @ 1A 28VDC for alarm reporting.
10 Mins./6A
30 Mins./6A
Maximal5FDV
5 Mins./10A
30 Mins./10A
Over 2 Hours/10A
Over 4 Hours/10A
Maximal7FDV
5 Mins./10A
30 Mins./10A
Over 2 Hours/10A
Over 4 Hours/10A
- 7 -
