Enclosure Dimensions - Altronix Maximal11FDV Installation Manual

1.25"
(31.75mm)
8.5"
(215.9mm)
7.5"
(190.5mm)
26"
(660.4mm)
LEFT
10"
(254mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIMaximal11FDV/33FDV/55FDV/75FDV/77FDV Series
Maximal11FDV / Maximal33FDV / Maximal55FDV / Maximal77FDV / Maximal75FDV Access Power Controllers (PTC)
Enclosure Dimensions (H x W x D approximate):
26" x 19" x 6.25" (660.4mm x 482.6mm x 158.8mm)
2"
4"
(50.8mm)
(101.6mm)
0.85"
(21.59mm)
1.5"
(38.1mm)
26"
(660.4mm)
1"
(25.4mm)
0.85"
(21.59mm)
19"
(482.6mm)
7"
(177.8mm)
TOP
19"
(482.6mm)
8.9"
(226.06mm) (213.36mm)
8.9"
(226.06mm) (213.36mm)
BOTTOM
19"
(482.6mm)
G31R
2"
4"
(50.8mm)
(101.6mm)
6.25"
(158.75mm)
0.85"
8.4"
(21.59mm)
1.5"
(38.1mm)
5"
(127mm)
7.5"
(190.5mm)
1"
(25.4mm)
8.4" 0.85"
(21.59mm)
6.25"
(158.75mm)
4" 2"
(101.6mm)
(50.8mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
7"
(177.8mm)
8.5"
(215.9mm)
26"
(660.4mm)
RIGHT
7"
(177.8mm)
2"
(50.8mm)
1.25"
(31.75mm)
MEMBER
