Enclosure Dimensions - Altronix AL802ULADA Installation Manual

1.25"
4.5" (114.3mm)
(31.8mm)
1.5"
(38.1mm)
2.0"
(50.8mm)
2.0"
(50.8mm)
1.25" (31.8mm)
Altronix is not responsible for any typographical errors .
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A .
IIAL802ULADA
- 16 -

Enclosure Dimensions:

15 .5" x 12" x 4 .5" (393 .7mm x 304 .8mm x 114 .3mm)
1.5"
4.615" (117.2mm)
(38.1mm)
12.23" (310.6mm)
1.1" (27.9mm)
1.5"
4.615" (117.2mm)
(38.1mm)
1.5"
4.615" (117.2mm)
(38.1mm)
1.1" (27.9mm)
1.1" (27.9mm)
1.5"
4.615" (117.2mm)
(38.1mm)
K15S
1.75"
(44.5mm)
4.5" (114.3mm)
1.375"
(34.9mm)
1.125"
(28.6mm)
1.25" (31.8mm)
1.75"
(44.5mm)
1.25"
(31.8mm)
1.5"
(38.1mm)
MEMBER
AL802ULADA
