Figure 27-111.Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
70
60
50
40
30
20
10
0
0
Figure 27-112.Reset Pull-up Resistor Current vs. Reset Pin Voltage (V
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
120
100
80
60
40
20
0
0
ATmega48P/88P/168P/328P
V = 2.7V
CC
25 °C
-40 °C
85 °C
0.5 1 1.5
V
RESET
V = 5V
CC
25 °C
-40 °C
85 °C
1 2 3
V
RESET
CC
2 2.5
(V)
CC
4 5
(V)
= 2.7 V).
3
= 5 V).
6
