VLT ® Automation Drive FC 300
Instruction Manual High Power

3. How to Install

3.1. How to Get Started

3.1.1. About How to Install
This chapter covers mechanical and electrical installations to and from power terminals and control
card terminals.
Electrical installation of
3.1.2. How to Get Started
The adjustable frequency drive is designed for quick installation and is EMC-compliant. Just follow
the steps described below.
Mechanical Installation
•
Electrical Installation
•
•
•
•
Quick set-up
•
•
•
Frame size is dependent on enclosure type,
power range and line voltage.
options is described in the relevant Instruction Manual and Design Guide.
Read the safety instructions before installing the unit.
Mechanical mounting
Connection to Line and Protecting
Ground
Motor connection and cables
Fuses and circuit breakers
Control terminals - cables
Local Control Panel, LCP
Automatic Motor Adaptation, AMA
Programming
MG.33.U1.22 - VLT ® is a registered Danfoss trademark.
3.1: Diagram showing basic installation including
line power, motor, start/stop key, and potentiom-
eter for speed adjustment.
