  • Page 1 PACKET REFERENCE MANUAL TCADTP2PR Rev. AD 8/18 2017 Avery Dennison Corp. All rights reserved. Classification: Avery Dennison - Public...
  • Page 2 2017 Avery Dennison Corp. All rights res erved. No part of this publication may be reproduced, trans mitted, stored in a retrieval s ys tem , or translated into any language in any form by any m eans, without the prior written permiss ion of Avery Dennis on Corp.

  • Page 3: Table Of Contents

    Defining the Backfee d Control Packet ................. 2-17 Spec ial Considerations W hen Using Backfeed ............2-18 Defining the Mem ory Configurati on Packet ..............2-19 Checking Current Buffer Siz es ................. 2-20 Classification: Avery Dennison – Public Table of Contents i...
  • Page 4 Merg ing Fie lds......................4-6 Sub-Fields.........................4-6 Using Option 5 (Define Data Entry Sourc es ) ..............4-6 Us ing Option 6 ( Uploa d Field Data) ................4-7 Us ing Option 7 Print T ime/Date ..................4-9 ii Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 5 Sample Hex Gra phic Pac ket..................5-10 Sample Run Length Grap hic Packet ................5-10 Placing the Graph ic in a Format .................. 5-11 Defining the Graphic Fie ld ..................5-12 Classification: Avery Dennison – Public Table of Contents iii...
  • Page 6 ENQ Reference Table - Byte #2 ..................7-2 ENQ Reference Table - Byte #3 ..................7-4 Job Request .........................7-6 Job Res ponse ......................7-6 Job Status Respons es ....................7-8 Status Polling Considerations for Script Mode ...............7-9 iv Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 7 Sample Data Matr ix Packets ..................A-4 Square Data Matrix Pac ket ..................A-4 Rectangular Data Matrix Pac ket ................A-4 Sample Data Matr ix with Func tion 1 ................A-5 Classification: Avery Dennison – Public Table of Contents v...
  • Page 8 ASCII HE X Increm enting Field ..................A-15 SSCC96 ........................A-16 SGTIN 96 ........................A-17 Password Lock ......................A-18 Permalock and Pas sword Lock .................A-18 RFID Data Field with Ser ializ ed EPC Data Option .............A-18 vi Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 9 Online Configurati on W orks heet ................... D-2 Supply La yout Gr ids (English) ..................D-3 Supply La yout Gr ids (Me tric)..................D-4 Supply La yout Gr ids (Dots) ..................D-5 GLOSSARY .........................G-1 Classification: Avery Dennison – Public Table of Contents vii...
  • Page 10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 11: Getting Started

    B ,1 ,12,F,8 5,40,1,2,40 ,5,L,0 | 4. Type the following text field: T,2,18,V,50,50,1,1,1,1,B,L,0,0,1 | } This is an MPCLII form at pac ket. Next, c reate a batch packet before printing the format. Classification: Avery Dennison – Public Getting Started 1-1...

  • Page 12: Sample Batch Packet

    ? There are s everal steps to designing a custom format: Determine the label siz e. Labels are available from Avery Dennison in a wide variety of sizes. The application and the am ount of printed data determine the supply size. Contact your Account Manager or Technical Support for m ore information.

  • Page 13: Rfid Format Design Tips

    (bac king paper) in this dimension. Enter the label width for param eter f7. width in the form at header. See “Defining the Form at Header” for m ore information. Classification: Avery Dennison – Public Getting Started 1-3...

  • Page 14: Determining The Print Area

    . English or Metric units allow more direct use of formats on printers with different density printheads . Supply layout grids are in Appendix D, “Format Des ign Tools.” 1-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 15: About Field Types

    RFID inlay. All of the above field types exc ept graphics are discussed in Chapter 3. See Chapter 5, “Creating Graphics” for inform ation on inc luding graphic s in the format. Classification: Avery Dennison – Public Getting Started 1-5...
  • Page 16 1-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 17: Configuring The Printer

    Shift key plus the Split Vertic al Bar key on the computer’s keyboard. Depending on the text editor, it may appear as a solid vertical bar or as a split vertic al bar. Classification: Avery Dennison – Public Configuring the Printer 2-1...

  • Page 18: Standard Syntax Guidelines

    Use a tilde (~) followed by a 3-digit ASCII code in a quoted string to send function codes or extended characters or send the 8-bit ASCII code. Modify form ats and fields with the optional entry m ethod. See “Optional Entry Method” in Chapter 6 for more inform ation. 2-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 19: Using Online Confi Guration Pac Kets

    (|) mus t s pec ify distances us ing the selected units. However, the tes t labels display the units in dots , even if entered in Englis h or Metrics units. Classification: Avery Dennison – Public Configuring the Printer 2-3...
  • Page 20 23995 is the memory available in volatile RAM. There is no non-volatile RAM available. The remaining lines beginning with M list the buffer sizes in 1/10K for the Image, Downloadable Fonts, and Formats Buffers. 2-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 21: Configuration Syntax Guidelines

    A4. sep_on Batch Separators. 0 is the default. Do not use batch separators with continuous (non-indexed) supply.Options: Does not print a separator Prints a separator Double-length separator – print 2 tags Classification: Avery Dennison – Public Configuring the Printer 2-5...
  • Page 22 Powers up the printer in the online m ode, displays prompts in Englis h, prints a s eparator after each batch, prints zeros with s lashes through them , and uses the internal symbol s et. 2-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 23: Defining The Su Pply Set Up Packet

    Settings for ribbon and supply type must match the supplies loaded in the printer; otherwise, an error occurs. To clear the error, change the configuration packet and resend it. Classification: Avery Dennison – Public Configuring the Printer 2-7...
  • Page 24 The Ec oCut printer cuts after each tag and eac h tag is 3.0 inches long (609 dots). 2-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 25: Defining The Prin T Control Packet

    2.5 ips. Serial bar codes printed at speeds greater than 2.5 ips m ay not scan properly. C6. ph_width W idth of the printhead in dots. Use 0. C7. bat_v olt Battery voltage. Us e 0. Classification: Avery Dennison – Public Configuring the Printer 2-9...

  • Page 26: Defining The Monetar Y Form Atting Pac Ket

    One digit Two digits Three digits Exam ple {I,D,1,1,2 | } Prints the dollar sign, uses a secondary symbol, and places two digits to the right of the dec im al. 2-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 27: Defining The Contro L Charac Ters Pac Ket

    Send the c ontrol charac ters pac ket to enable the imm ediate commands. An imm ediate c om m and executes immediately, even if it is em bedded within quotation marks, and all data following the com mand in the string is ignored. Classification: Avery Dennison – Public Configuring the Printer 2-11...

  • Page 28: Resetting Control Characters

    Im m ediately cancels the batch currently printing unless an error exists in the printer. This exam ple assumes that the defined imm ediate c om mand control character is the c aret (^). 2-12 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 29 It has the same effect as turning off and then turning on the printer. This command should be used only when the printer is not printing. Classification: Avery Dennison – Public Configuring the Printer 2-13...

  • Page 30: Using The Ack/Nak Protocol

    If five consecutive m es sages have been kept in RAM without receiving an ACK res pons e, the printer stops with the error m es sage “Waiting fo r Hos t”. The operator c annot clear this error and no printer buttons are active. 2-14 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 31: Uploa Ding Rf Id Data

    EPC data (if any) is returned. Exam ple {F,1,A,R,E,300,150,”RFID”| X,1,24| R,60 |} {B ,1,N,999| 1,”30 34 567 8901234567890AB01”|} The printer returns: 30 345678901234567890 AB01 Classification: Avery Dennison – Public Configuring the Printer 2-15...

  • Page 32: Defining The Com M Unic Ation Settings Pac Ket

    Flow Control to DTR (not XON/XOFF).Options: None 2 (CTS) DTR (default) 3 XON/XOFF Exam ple {I,F,3,1,0,0,1 | } Uses 9600 baud, an 8-bit word length, one stop bit, no parity, and the DTR mode. 2-16 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 33: Defining The Backfee D Control Packet

    However, that adds a 30 dot non-print zone on the s upply. Exam ple {I,G,1,50,20 | } Enables backfeed and s ets the dispense pos ition to 0.25 inches (50/203) and the backfeed distance to 0.10 inches (20/203). Classification: Avery Dennison – Public Configuring the Printer 2-17...

  • Page 34: Special Considerations When Using Backfeed

    See the following graphic for a representation of the following adjustm ents: dispense position, backfeed dis tance, supply pos ition, print pos ition, and m argin position. 2-18 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 35: Defining The Mem Ory Configurati On Packet

    Thes e buffers cannot be c hanged. Exam ple {I,M ,I,R,1 530 | } Stores the image buffer in volatile RAM and alloc ates 153K for it. Classification: Avery Dennison – Public Configuring the Printer 2-19...

  • Page 36: Checking Current Buffer Siz Es

    See “Us ing the Font Pac ket” for more information. Fonts stored in this buffer are deleted when the printer is turned off. Store downloaded fonts into flash m em ory. 2-20 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 37: Buffer Allocation Considerations

    ADK script files do not exc eed this am ount. For exam ple, if the printer displays “Unused Flash 10223616,” there is 9984K (9.75 Meg) of available flash mem ory for fonts or ADK sc ript files. Flash memory cannot be reallocated. Classification: Avery Dennison – Public Configuring the Printer 2-21...

  • Page 38: Flash Memory Guidelines

    3. action Ac tion. Enter C to c lear the pac ket. 4. device Storage device. Options: Flash Volatile RAM Exam ple {F,1,C,R | } Clears Format #1 from volatile RAM. 2-22 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 39: Defining The T Im E/Date Packet

    June December T6. year Year (as two-digit). Range: 0 to 99. 15 is 2015. Exam ple {I,T,18,15,1 2,06,15 | } Sets the printer’s cloc k to 6:15 pm June 12, 2015. Classification: Avery Dennison – Public Configuring the Printer 2-23...

  • Page 40: Using The Font Pac Ket

    Selects all fonts and checks the memory usage in RAM. The printer returns the following to the host: {W,0 ,M ,R | Numbe r of byte s fre e , Numbe r of byte s us ed | } 2-24 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 41 0,15,0,"CGTriumv7",1,0,7,21,28,9,14,0| 0,15,1,"CGTriumv7",1,0,7,21,28,9,14,0| 0,15,437,"CGTriumv7",1,0,7,21,28,9,14,0| In t e r - Ch aracter Gap 0,15,850,"CGTriumv7",1,0,7,21,28,9,14,0| 0,510,0,"CGTriumv7",1,0,7,21,28,9,14,0| 0,510,1,"CGTriumv7",1,0,7,21,28,9,14,0| 0,510,437,"CGTriumv7",1,0,7,22,28,9,14,0| 0,510,850,"CGTriumv7",1,0,7,22,28,9,14,0| 0,16,0,"CGTriumv9",1,0,8,28,35,12,18,0| 0,16,1,"CGTriumv9",1,0,8,28,35,12,18,0| 0,16,437,"CGTriumv9",1,0,8,28,35,12,18,0| 0,16,850,"CGTriumv9",1,0,8,28,35,12,18,0| 0,511,0,"CGTriumv9",1,0,8,28,35,12,18,0| 0,511,1,"CGTriumv9",1,0,8,28,35,12,18,0| 0,511,437,"CGTriumv9",1,0,8,29,35,12,18,0| 0,511,850,"CGTriumv9",1,0,8,29,35,12,18,0| 0,17,0,"CGTriumv11",1,0,9,31,40,13,22,0| 0,17,1,"CGTriumv11",1,0,9,31,40,13,22,0| 0,17,437,"CGTriumv11",1,0,9,31,40,13,22,0| 0,17,850,"CGTriumv11",1,0,9,31,40,13,22,0| 0,512,0,"CGTriumv11",1,0,9,31,40,13,22,0| 0,512,1,"CGTriumv11",1,0,9,31,40,13,22,0| 0,512,437,"CGTriumv11",1,0,9,33,40,13,22,0| Classification: Avery Dennison – Public Configuring the Printer 2-25...
  • Page 42 Dis plays whether a 203 (0) dpi or 300 (1) dpi printhead is used. The s c alable font (font 50) does not dis play which printhead (203 dpi or 300 dpi) is used. 2-26 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 43: Uploa Ding Format He Ader Information

    Exam ple {F,1 ,H,Z | } Selects format1 and returns the following to the host: {F,1,H,Z | Fmt_1 ,4 06,406 | } Displays the supply length and s upply width (in dots ) for format1. Classification: Avery Dennison – Public Configuring the Printer 2-27...

  • Page 44: Defining A Network Console Packet

    Sends the network console pac ket m ys tore direc tly to the wireless m odule (T ) and sets the IP method to static for determ ining the IP Address es. The Init and Exit com mands mus t be used to save changes and initializ e the wireless module. 2-28 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 45: Defining The Rf Id Setup Packet

    ‘hots pot’ of the first inlay over the antenna s o the TID order can be calc ulated. Us e the RFID Printer Setup Utility to determ ine this value. The range is 0 to 2000 in 1/203 inc h. 0 is the default. Classification: Avery Dennison – Public Configuring the Printer 2-29...
  • Page 46 3 - both). Sets the pos ition for when the label’s leading edge reaches the external verifier. Us e the RFID Printer Setup Utility to determine this value. The range is 10 to 2000 in 1/203 inc h. 100 is the default. 2-30 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 47: Performance Considerations With Rfid

    RFID chip. ♦ The printer errors if it c annot program all the RFID data while the inlay is within the enc ode z one. Classification: Avery Dennison – Public Configuring the Printer 2-31...
  • Page 48 2-32 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 49: Defining Fields

    . “ ” is the default. The range is 1 to 256 c harac ters for the XML-enabled printer. Exam ple {F,1,A,R,E,3 00,200,"TEXTILES" | Adds Format 1 (“TEXTILES”) to the printer. It us es a three inch long by two inch wide label. Classification: Avery Dennison – Public Defining Fields 3-1...

  • Page 50: Defining Text Fields

    10 is the default. Englis h 0 – 409 Metric 0 – 1039 203 Dots 0 – 831 300 Dots 0 – 1247 3-2 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 51 “W ” for the widest field or an “L” for an average width field. Find the selected font and the des ired width in Appendix B, “Fonts .” Classification: Avery Dennison – Public Defining Fields 3-3...
  • Page 52 Us e L, B, or E for any font. The red dot indic ates the field origin and the line indicates the colum n position for each field in the following graphic. 3-4 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 53 0 Top of field points to top of supply 1 Top of field points to left of supply 2 Top of field points to bottom of supply 3 Top of field points to right of supply Classification: Avery Dennison – Public Defining Fields 3-5...
  • Page 54 250, column 80. There is no additional gap between charac ters , and the Standard font is us ed without any additional magnific ation. The printing is black on white and centered. No field or character rotation is used. The internal s ymbol set is used. 3-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 55: Defining Bar Code Fie Lds

    0 – 2710 Code 93 0 – 2710 Code 128 0 – 2710 Data Matrix 0 – 2710 numeric; 0 – 2335 alphanum eric EAN8 EAN8+2 EAN8+5 EAN13 EAN13+2 EAN13+5 EAN13+Price CD Classification: Avery Dennison – Public Defining Fields 3-7...
  • Page 56 W hen inc reasing the error correction level, the maximum number of charac ters decreases. See “Entering Batch Data for QR Code” in Chapter 6 to enter data for the QR Code. 3-8 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 57 Fixed EAN13+5 Fixed UPCE+2 Fixed EAN13+Price CD Fixed UPCE+5 Fixed GS1 DataBar Fixed or Variable For m ore inform ation about the two-dimens ional bar codes, see Appendix A, "Sam ples .” Classification: Avery Dennison – Public Defining Fields 3-9...
  • Page 58 UPCA +2 Intelligent Mail EAN13 & Price CD Interleaved 2 of 5 with Barrier Bar B8. dens ity Bar code density. The default varies by bar code type. Use the following tables. 3-10 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 59 12, produc es a one-dot narrow bar. This dens it y is int ended for s pec ial U. S . P . S . A CT-t ag applic at ions only . S y nt het ic s upplies are rec ommended t o produc e s c annable bar c odes . Classification: Avery Dennison – Public Defining Fields 3-11...
  • Page 60 0 - 486 (8-bit); 0 - 299 (Kanji) and 2 Model 2: 0 - 2710 Numeric, Alphanumeric and 8-bit; 0 - 1817 Kanji Note : Values in bold indicate the default. 3-12 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 61 Avery Dennis on “premium” supplies and increasing the print c ontrast are recom mended for denser bar codes. Depending on the applic ation, additional densities are available. Classification: Avery Dennison – Public Defining Fields 3-13...
  • Page 62 7/34.5 8/39.4 Aztec 0.0099 0 to 2710 00H to FFH 0.0148 0.0197 0.0247 0.0296 0.0345 0.0394 0.0444 0.0493 0.0542 0.0592 0.0641 0.0690 0.0740 Note : Values in bold indicate the default. 3-14 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 63 Code 39. Code 93, density 12, produces a one-dot narrow bar. This dens ity is intended for s pecial U.S.P.S. ACT-tag applic ations only. Synthetic s upplies are recomm ended to produce sc annable bar codes. Classification: Avery Dennison – Public Defining Fields 3-15...
  • Page 64 (dots/mils) Ratio Le ngth Code s (dot/mils) 3/10.0 0 to 2709 00H to PDF417 3/10.0 3/10.0 6/20.0 3/10.0 9/30.0 4/13.3 4/13.3 4/13.3 9/30.0 4/13.3 12/40.0 6/20.0 6/20.0 6/20.0 12/40.0 6/20.0 18/60.0 3-16 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 65 8/26.2 10/32.8 11/36.1 Aztec 0.0100 0 to 2710 00H to FFH 0.0133 0.0167 0.0233 0.0266 0.0333 0.0366 0.0433 0.0466 0.0533 0.0566 0.0633 0.0666 0.0733 Note : Values in bold indicate the default. Classification: Avery Dennison – Public Defining Fields 3-17...
  • Page 66 20 is the default for Code 93. Code 93 40 is the default for UPCA/UPCE/EAN, I 2of5, EAN/UPCA/UPCE I 2of5 Codabar, Code 39, Code 128, and MSI. Codabar Code 39 Code 128 3-18 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 67 Chec k digit and number s ys tem at bottom (default) MaxiCode MaxiCode (auto detect modes 0, 2, 3, or for c ompres sed data) default All other bar codes No text, bar code only (default) Classification: Avery Dennison – Public Defining Fields 3-19...
  • Page 68 Align at endpoint of the field; right justifies variable-width bar c odes . The red dot indic ates the field origin and the line indic ates the c olumn pos ition for each field in the following graphic. 3-20 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 69 40. A UPCA bar c ode with a dens ity of 2 and a height of 80 is used. The c hec k digit and num ber system are s hown at the bottom . The bar code is left aligned without any field rotation. Classification: Avery Dennison – Public Defining Fields 3-21...

  • Page 70: Defining Non-Printabl E Text F Ields

    Maximum number of characters in this field: 0 to 2710. 30 is the default. Exam ple D,4,20 | Defines a non-printable text field (field #4) with a m aximum of 20 charac ters . 3-22 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 71: Defining Constant Text F Ields

    CG Trium virate™ Typefac e Bold 7 pt. CG Triumvirate™ Typeface OCRA-like 9 pt. CG Triumvirate™ Typeface 11 pt. CG Triumvirate™ Typeface 15 pt. CG Triumvirate™ Typefac e EFF Swiss Bold (TrueType® Sc alable) PaxarSymbols Classification: Avery Dennison – Public Defining Fields 3-23...
  • Page 72 Note : Solid blac k print should not exceed 30% on a given s quare inch of the label, or the printhead life may be decreased 3-24 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 73 Top of field points to top of supply Top of field points to left of supply Top of field points to bottom of supply Top of field points to right of supply Classification: Avery Dennison – Public Defining Fields 3-25...
  • Page 74 No field or c harac ter rotation is used. “MADE IN USA” is printed in this field. The internal symbol set is us ed. 3-26 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 75: Defining Li Ne Fiel Ds

    0 – 4063 203 Dots 0 – 3247 300 Dots 0 – 3599 If Us ing Vec tors : Angle of line. Options: 0, 90, 180, or 270. 0 is the default. Classification: Avery Dennison – Public Defining Fields 3-27...
  • Page 76 Defines a horizontal line field as a segm ent s tarting at row 110, column 30 and ending at row 110, colum n 150. The line thicknes s is 10 dots . 3-28 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 77: Defining Box F Ields

    Distanc e from left edge of print area to upper right c orner of box. 100 is the default. Englis h 0 – 409 Metric 0 – 1039 203 Dots 0 – 831 300 Dots 0 – 1247 Classification: Avery Dennison – Public Defining Fields 3-29...
  • Page 78 Q,2 40,30,27 0,150 ,3 ,"" | Defines a box field starting at row 240, column 30. It ends at row 270, column 150. It has a thic kness of 3 dots. 3-30 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 79: Defining The Rf Id Data Fiel D

    Do not use the ASCII file separator charac ter (1C) in RFID batc h data. Exam ple X,5,24 ,0 | Defines an RFID Data Field (field #5) with exac tly 24 ASCII Hex characters for a 96-bit RFID inlay. Classification: Avery Dennison – Public Defining Fields 3-31...
  • Page 80 3-32 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 81: Defining Field Options

    Define optional s ettings for Aztec bar codes Define inc rementing or decrem enting field Reimage fields Serializ ed EPC data R3. param eter(s) Varies per option. See the following option descriptions. Classification: Avery Dennison – Public Defining Field Options 4-1...

  • Page 82: Us Ing Option 1 (Fi Xed Data)

    Spac es are permitted in all categories . Use a com bination of any two (letter, numbers, or symbols) character types. Exam ple R,2,2 | Restricts the field data to letters only (A-Z or a-z). 4-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 83: Using Option 3 (Data Entry T Em Plates)

    Creates a template that allows any printable c harac ter in positions 1, 2, and 3; digits in pos ition 4; and reserves positions 5 through 8 for fixed or c opied data. Classification: Avery Dennison – Public Defining Field Options 4-3...

  • Page 84: Using Option 4 (Copy Data)

    Copies data from field #3, s tarting at the first position and copying three c haracters. In the destination field, the information is plac ed in position 1 and copied as formatted data. 4-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 85: Rfid Ascii Hex Data Convert To Ascii Decimal Example

    (303 40 FFFFF7777C98DF3EA6D) to ASCII Decimal data then printed. Fif t h p r in t e d lab e l Fir s t p r in t ed lab e l Classification: Avery Dennison – Public Defining Field Options 4-5...

  • Page 86: Merging Fields

    Allows data to be entered from a keyboard. Exam ple T,2,10,V,25 0,50,0,1,1,1,B,C,0,0,0 | R,5,R | Reads the pre-programm ed data from the RFID chip and saves that data into the text field. 4-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 87: Us Ing Option 6 ( Uploa D Field Data)

    Type of data to upload. Us e T to upload the TID (tag identifier). Configure the RFID Setup Pac ket to enable s ingulate m ode first. Exam ple T,2,10 ,V,25 0,50,0,1,1,1,B,C,0,0,0 | R,6,H | Uploads the text field’s data to a file. Classification: Avery Dennison – Public Defining Field Options 4-7...
  • Page 88 3 1323334353637 383930 313 2 Exam ple B ,3,12,F,50,50,1,2,60 ,7 ,L,0 | R,6 ,H | Returns the following UPCA bar code data entered from the batc h in the upload pac ket: 1 23456789012 4-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 89: Us Ing Option 7 Print T Ime/Date

    The prompt mus t be 15 c haracters or less . Exam ple R,2 0,"Order Numbe r" | Displays the prompt Order Number for the operator when this field is imaged. Classification: Avery Dennison – Public Defining Field Options 4-9...

  • Page 90: Using Option 21 (Defin E Extend Ed Fiel D Names)

    If the maxim um num ber of c harac ters in the bar c ode is 15, but the batch packet only has 10 characters, the padding option fills the remainder of the field with pad characters. 4-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 91: Using Option 31 (Calc Ulate Chec K Digit)

    Exam ple R,42,1 | Uses a price field that prints the m onetary s ymbol and notations as defined in the m onetary formatting packet. Classification: Avery Dennison – Public Defining Field Options 4-11...

  • Page 92: Using Option 50 (Bar Code Dens Ity)

    300 dpi. This sam ple does not I 2of5 use Option 50. B ,4,1 2,V,125,40,3,12,8 0,8,L,0 | De f au lt De n s it y 4-12 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 93 Exam ple B ,1,40,V,10 0,100,32,1,0,8,L,0 | 50,3,15 | Creates a custom PDF417 bar c ode density for 300 dpi printers. The narrow element width is 3 dots and the height is 15 dots . Classification: Avery Dennison – Public Defining Field Options 4-13...

  • Page 94: Using Option 51 (Pdf417 Sec Urity/Truncatio N)

    . 1 is the default for columns. Exam ple R,52,C,10 | Defines the colum n width of 10, whic h expands the PDF417 bar c ode length by 10. 4-14 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 95: Using Option 53 (Option Al Settin Gs For Aztec)

    Uses option 53 to set the error c ontrol to 0, dis ables the ECI data and menu s ym bol flags, and does not append any data to the bar c ode. Classification: Avery Dennison – Public Defining Field Options 4-15...

  • Page 96: Using Option 60 ( Inc Rementing/Decrementing Fields)

    RFID Dat a Fie ld Bat ch {B ,1,N,3| Dat a in ASCII He x w it h 1,"001"| EPC Dat a in clu d e d 2,"123456789012"| 3,"1234567812345678 123456 1B~0 28~028~02812345678~02812345678 ~0280 000 0~028"| } 4-16 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 97: Fixing The First Number In The Incrementing Sequence

    In this example, Option 61 is applied to the bar code field to keep the increm enting field (Box #) from blocking out the bar code field. Re - Im ag e ON Re - Im ag e OFF Classification: Avery Dennison – Public Defining Field Options 4-17...

  • Page 98: Using Option 65 (Seria Lized Epc Data)

    The RFID data field inc ludes zeroes s o the field's maximum number of charac ters is 96 bits of data (24 ASCII Hex charac ters ). The enc oded RFID data contains the first 58 bits of provided EPC data and 38 bits of the calc ulated serial number. 4-18 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 99: Using Check Digits

    5. The chec k digit is calculated by us ing the Sum of Produc ts and the string of digits used in the c alc ulation is “65432.” Classification: Avery Dennison – Public Defining Field Options 4-19...

  • Page 100: Sum Of Products Calculation

    5. Subtract the rem ainder from the m odulus. The result becom es the c hec k digit. In this c ase, the check digit is 2. 10 - 8 = 2 4-20 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 101: Sum Of Digits Calculation

    10 44 5. Subtract the remainder from the modulus . The result bec omes the check digit. In this c ase, the c heck digit is 6. 10 - 4 = 6 Classification: Avery Dennison – Public Defining Field Options 4-21...
  • Page 102 4-22 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 103: Creating Graphics

    The mos t efficient enc oding method depends on how com plic ated the graphic image is and whether or not imaging tim e is a c oncern. Experiment with both encoding m ethods to get optim al performanc e. Classification: Avery Dennison – Public Creating Graphics 5-1...

  • Page 104: Des Igning Bitmapped Images

    Do e s n o t Exce e d s 0.5” e xce e d lim it lim it Do e s n o t Exce e ds e xce e d lim it lim it 5-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 105: Using The Hex Method

    1, pos ition 49 = 03 FFFFFF00 000 5. Repeat steps 3 through 4 for eac h row on the grid. 6. Ins ert the hex values in s yntax form at. Classification: Avery Dennison – Public Creating Graphics 5-3...

  • Page 106: Using The Run Length Encoding Method

    For exam ple, uZFu can be written as uZF. 4. Repeat steps 1 through 5 for each row on the grid. 5. Insert the c ode values in s yntax format. 5-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 107: Determining How To Store The Im Age

    Instead, position the graphic image by using the row and column locations in the graphic packet header. Image m em ory (temporary s torage) will ac cept a graphic packet 1218 rows long with 811 dots per row. Classification: Avery Dennison – Public Creating Graphics 5-5...

  • Page 108: Creating A Grap Hic Packet

    The bottom of the triangle in this example repres ents the first field of the graphic pac ket starting at 10,0. 5-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 109: Defining The Graphic Header

    10 is the default. See “Positioning the Graphic Image,” for m ore inform ation. English 0 – 409 Metric 0 – 1039 203 Dots 0 – 831 300 Dots 0 – 1247 Classification: Avery Dennison – Public Creating Graphics 5-7...

  • Page 110: Creating Bitm Ap Fields

    Exam ple B ,39,56,H,"3FFFFFF0 " | Defines a bitmapped graphic field. The im age begins 39 dots from the bottom and 56 dots from the left edge of the graphic area. Hex representation is us ed. 5-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 111: Creating Ne Xt-Bitm Ap Fields

    The above example adjusts the duplicate field to im age on row 70 and 90 (adding 20 to the current row c ount). D4. count Number of times to duplicate the line. Range: 0 to 999. Classification: Avery Dennison – Public Creating Graphics 5-9...

  • Page 112: Sample Hex Gra Phic Pac Ket

    B ,77,8,H,"0FFFCFFC0000 000 000000 1C0" | B ,1 22,24,H,"07FFFFFFFFFFFFFFFC" | B ,78,16,H,"FFDF000FFFFFFFFF800 3C0 " | B ,1 23,32,H,"FFFFFFFFFFFFFFC0" | B ,79,16,H,"7 FFFC0000 7FFFF00001FC0" | B ,80,24,H,"1C03FFFFFFFFFFFE0 1C0" | D,0,4,4 | B ,81,32,H,"3FFFFFFFFFFFFFE1C0" | D,0,4,4 | 5-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 113: Placing The Graph Ic In A Format

    3. Download all the nec ess ary packets (c heck digit, form at, etc.). 4. Send the graphic file to the printer. See “Creating a Graphic Packet” for more inform ation. Classification: Avery Dennison – Public Creating Graphics 5-11...

  • Page 114: Defining The Graphic Fie Ld

    Sam ple Batc h Packet {B ,2 ,N,1 | 1,"Pat’s " | 2,"Parts " | 4 ,"3.55 /8 Pack " | 5 ,"345 911871209" | } 3,"3/8 inch Wire " | 5-12 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 115: About The Compressed Graphics Pac Ket

    The im age is placed at row 10 and column 10. The image contains 25 rows and 50 columns of data. The file siz e is 256 bytes and the image is c alled LOGO. Classification: Avery Dennison – Public Creating Graphics 5-13...

  • Page 116: Dot To Run Length Enc Oding Chart

    D o t to Ru n L e n g th En c o d in g Ch a r t ON (Black) Dots # of Dots Code # of Dots Code Off (White Dots) # of Dots Code # of Dots Code 5-14 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 117: Printing

    ♦ Check digit pac kets (s ee Chapter 4) ♦ Format packets (s ee Chapter 3) ♦ Graphic packets (s ee Chapter 5) 4. Batc h data (see “Defining the Batc h Header”) Classification: Avery Dennison – Public Printing 6-1...

  • Page 118: Downloading Fil Es

    ♦ 802.11 a/b/g/n Connect to the printer us ing MonarchNet2™ or other software to download files . Refer to the M onarchNet2 Operating Instruc tions for more information 6-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 119: About Batch Packets (Print Jobs )

    Method” for more information. Exam ple {B ,1 ,N,5 | Defines a batch header that us es form at #1 and reimages all fields using the online data. Five labels are printed in this batc h. Classification: Avery Dennison – Public Printing 6-3...

  • Page 120: Defining The Batch Control F Ield

    The last tag in the batch is always c ut, regardless of the m ultiple. E8. ver_m ode Bar code verifier m ode. Use 0. E9. cable_det Bar code verifier cable detec t. Use 0. 6-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 121: Defining Batc H Data Fields

    In incrementing fields , the firs t num ber in the s equence m ust contain the sam e number of digits as the highest num ber to be c ounted. For example, to inc rement the numbers in a field from 1 to 999, enter the starting number in the batch as 001. Classification: Avery Dennison – Public Printing 6-5...

  • Page 122: Creating Gen2 Rfid Data

    EPC and user memory are never rewritable, but are (permanently readable. locked) Acc ess pas sword and kill password are never readable or rewritable. Note : The EPC field is always readable, no matter what locking method is assigned. 6-6 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 123 If the printer cannot program all the RFID data within the allotted time, an error occurs . C,"TID_M em ~028" Identifies information to be appended. Reserved for future use. Only include the field s eparator (decimal 028) in this field. Classification: Avery Dennison – Public Printing 6-7...
  • Page 124 EPC, us er m em ory, TID, and kill field. Selects no lock (0) for the acces s pas sword field. The EPC, user m em ory, TID, and kill fields are pe rmane ntly readable/writable. 6-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 125: Entering Batch Data For Qr Code

    Sets the QR Code’s error c orrec tion level to L, which provides high density (more data in bar code); leaves the m as k number blank; s ets the data input mode to Autom atic and the data is testdatainAutomode0987654321. Classification: Avery Dennison – Public Printing 6-9...

  • Page 126: Structured Append Mode

    (05) sym bols. The parity byte is E9. The error correction level is Q, which provides a high reliability. Use 0 for the mask number. The data input mode is Automatic. The type of characters are binary (B) and there will be six (06) data characters (qrcode). 6-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 127: Structured Append Qr Code Packet

    The printer images the field, but does not print it. After the operator enters the data for the last field, the batch quantity c an be specified. The las t remaining field is imaged, and the label prints alm ost immediately. Classification: Avery Dennison – Public Printing 6-11...

  • Page 128: Mo Difyi Ng Formats

    M ODE COM 1 : 9 600,N,8,1 ,| CD\M ONARCH COPY LAB EL1.CDS COM 1 COPY LAB EL1.FMT COM1 COPY LAB EL1.BCH COM1 6-12 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 129: Status Polling

    Indicates the printer is offline. The following graphics can be used as a quick referenc e for the Status of Byte #2 and Byte #3. Byte #1 is the non-printable us er-defined ENQ character. Classification: Avery Dennison – Public Status Polling 7-1...

  • Page 130: Enq Reference Table - Byte #2

    Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Note : A “1" indic ates the bit is turned on. A ”0" indicates the bit is off. 7-2 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 131 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Dec 127 Note : A “1" indic ates the bit is turned on. A ”0" indicates the bit is off. Classification: Avery Dennison – Public Status Polling 7-3...

  • Page 132: Enq Reference Table - Byte #3

    Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Note : A “1" indic ates the bit is turned on. A ”0" indicates the bit is off. 7-4 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 133 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Dec 127 Note : A “1" indic ates the bit is turned on. A ”0" indicates the bit is off. Classification: Avery Dennison – Public Status Polling 7-5...

  • Page 134: Job Request

    Status 0, 1, 2 Response Table” later in this chapter for brief explanations for J, 0, 1, 2 requests . In the above exam ple, refer to error 8 for an explanation. 7-6 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 135 “FMT -1/BCH-2" The format or batch num ber is returned. Exam ple {J,8 ,25,"FMT-3","Bch-2"} 8 out of 25 tags or labels are left to print from format number 3. Classification: Avery Dennison – Public Status Polling 7-7...

  • Page 136: Job Status Responses

    Stop location of a line is out of range Syntax error Cannot use offline format for online batch Cannot queue graphic batc h Cannot store online format Cannot queue online batch Cannot queue online clear com m and 7-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 137: Status Polling Considerations For Script Mode

    If s tatus polling and im m ediate c om mands are NOT enabled through the I Packet, enabling status polling and immediate c om mands at the printer’s front panel has NO effec t. Classification: Avery Dennison – Public Status Polling 7-9...
  • Page 138 7-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 139: Diagnostics & Errors

    Printer” for more inform ation. The lines beginning with M show the printers m emory allocation, which can be c hanged. The units for s upply pos ition, etc. are displayed in dots, even if entered in English or Metric units. Classification: Avery Dennison – Public Diagnostics & Errors 8-1...

  • Page 140: Clearing An Error

    W henever the printer is turned off, all the information set through the online configuration packets (A-Y) is saved. See the s ec tions in Chapter 2, “Configuring the Printer,” for m ore inform ation about each packet. 8-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 141: Calling Technic Al Support

    Field ID num ber is outside the range 0 to 999. Field length exc eeds 2710. Row field pos ition is greater than the maximum s tock dimension. See “Defining Text Fields” in Chapter 3 for valid row lengths . Classification: Avery Dennison – Public Diagnostics & Errors 8-3...
  • Page 142 GS1 DataBar separator height is invalid. See “Defining Bar Code Fields ” in Chapter 3 for more inform ation. GS1 DataBar segm ent width is invalid. See “Defining Bar Code Fields” in Chapter 3 for more inform ation. 8-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 143: Batch Errors

    The increm enting am ount m us t be 0 to 999. Security value for a PDF417 bar c ode mus t be 0 to 8. Correct the value and res end the format to the printer. Classification: Avery Dennison – Public Diagnostics & Errors 8-5...

  • Page 144: Online Configuration Errors

    Ribbon selection mus t be 0 (direc t), 1 (transfer), or 2 (high energy). Feed mode must be 0 (continuous ) or 1 (on-demand). Supply position must be -300 to 300 dots. Contrast adjustment m us t be -699 to 699 dots. 8-6 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 145 Backfeed distanc e m us t be 10 to 200 dots or the printer is active. The backfeed distance c an not be greater than the dis pens e pos ition. Classification: Avery Dennison – Public Diagnostics & Errors 8-7...

  • Page 146: Check Digit Errors

    RFID encode position must be between 0 and 2000. See “Defining the RFID Setup Packet” for m ore information. RFID stop to encode m ode mus t be 0 (dis abled) or 1 (enabled). See “Defining the RFID Setup Packet” for more inform ation. 8-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 147: Communication Errors

    Check the baud rate, word length, and stop bits to m ake sure they m atc h thos e at the host. Re-transm it the data. Classification: Avery Dennison – Public Diagnostics & Errors 8-9...
  • Page 148 An error occurred during the loop bac k test on the parallel port. Call Service. An error occurred during the loop back test on the s erial port. Call Service. 8-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 149: Data Formatting Failures

    An error oc curred opening the TrueType font file. Select a different font to download. If the error m ess age pers ists , c all Tec hnical Support. Classification: Avery Dennison – Public Diagnostics & Errors 8-11...

  • Page 150: Mac Hine Faults

    Too many inlays within the programmable range. Make s ure the read power is correct for the selec ted inlay. If the read power is c orrec t and this error occ urs, lower the read power by one and try again. 8-12 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 151 For exam ple, to perm aloc k an Impinj Monz a R6 c hip, us e “33333” for the lock c ode; otherwise, this error occurs. Classification: Avery Dennison – Public Diagnostics & Errors 8-13...
  • Page 152 Press ENT ER to c ontinue printing. Print a test label to c onfirm the num ber of bad dots. Backfeed/overfeed error. There is a problem with the backfeed or overfeed distance. Incorrect AD value. Call Tec hnical Support. 8-14 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 153: Flash Memory Errors

    The file in flash memory is full. Flash mem ory is not ac ces sible. An error occurred in the flash program. An error occurred while eras ing flash memory. Flash ID error. Classification: Avery Dennison – Public Diagnostics & Errors 8-15...

  • Page 154: Script Errors

    Error opening a font file on the print engine memory expans ion option. Error writing to a file on the print engine mem ory expansion option. Invalid condition for the print engine mem ory expansion option. 8-16 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 155: Hard Printer Fa Ilure Errors

    ACK or a NAK, it autom atically proc ess es any pending print jobs. If no unacknowledged log mess ages are saved, the printer res ponds with a NAK to any host ACK or NAK message. Classification: Avery Dennison – Public Diagnostics & Errors 8-17...
  • Page 156 8-18 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 157: Printer Optimization

    For highes t sc an rates, make sure there is adequate white spac e before and after the bar c ode. Also, a darker bar c ode does not mean it will s can better. Classification: Avery Dennison – Public Printer Optimization 9-1...

  • Page 158: Reducing Imaging T Im E

    4. For the last field, input data and s end it with the quantity of labels to print. W hen the printer receives input for the las t field, it imm ediately prints the labels . Exam ple {B ,1 ,U,10 | 5,"DAYTON, OHIO" | } 9-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 159: General Format Tips And Hints

    W hen fields are m agnified, they m ay go off the label or cover another field. Magnifying a field increases the distanc e between the printed c haracter and the edge of the cell. Classification: Avery Dennison – Public Printer Optimization 9-3...
  • Page 160 9-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 161: Samples

    C,25 9,23 2,0,1,1,1,B,L,0,0,"FRT B ILL # " | C,19 6,23 2,0,1,1,1,B,L,0,0,"FRT TERM S " | C,15 9,23 2,0,1,1,1,B,L,0,0,"KEYREC# " | C,12 5,23 2,0,1,1,1,B,L,0,0,"FRT CLAIM # " | C,09 0,23 2,0,1,1,1,B,L,0,0,"RECVD B Y " | Classification: Avery Dennison – Public Samples A-1...

  • Page 162: Sample Zero Batch Packet

    Code 93 is a linear one-dim ensional bar c ode that provides higher density than Code 39. {F,101 ,A,F,E,600,400,"EAN"| B ,2,12,V,225,50,23,7,8 5,8,L,0 | R,1,"1 23456789 0" | } {B ,1 01,N,1|} A-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 163: Sample Compliance Packet (Code 128 And Codabar Bar Codes

    R,1,"(4 2 0)ÿ" | T,1 6,2 7,V,27 0,10,0,3,1,1,B,C,0,0,0 | T,1 7,2 7,V,240,10 ,0 ,3,1 ,1 ,B,C,0 ,0 ,0 | R,1 ,"WELCOM ES GUEST # " | T,1 8,2 7,V,210,10 ,0 ,3,1 ,1 ,B,C,0 ,0 ,0 |} Classification: Avery Dennison – Public Samples A-3...

  • Page 164: Sample Batch Packet

    1,"12 34567890ABCDEFGHIJKLMNOPQRST" | } This exam ple prints a one-inch by a half-inch tall (50) rectangular 16 rows by 36 colum ns (density 29) Data Matrix sym bol rotated 90 (1). A-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 165: Sample Data Matr Ix With Func Tion 1

    {F,17,A,R,E,400,400,"STACKOM" | B ,1,120,V,5 0,100 ,38,3,100 ,0 ,L,0,4,2 | } {B ,17,N,1 | 1,"12 34567890123" | } GS1 DataBar Expanded with CC {F,1,A,R,E,400,400,""| B ,1,75,V,15,25, 38,2,0,0,L,0 ,6,1,4 |} {B ,1,N,1| 1,"01 93712345678904310300123 4|91 1A2B3C4D5E"|} Classification: Avery Dennison – Public Samples A-5...

  • Page 166: Gs1 Databar Expanded

    Se rial Numbe r 6 o r 9 digits : Range: 000000000 to 999999999 555555555 De liv ery Po int ZIP co de : 0, 5, 9, or 11-digit ZIP code A-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 167: Sample Ma Xicode Pac Kets

    UPS. Refer to the Guide to Bar Coding with UPS or the AIM MaxiCode Specification for m ore details about data requirem ents . The printer supports m odes 0, 1, 2, and 3. Contact Avery Dennison for information about additional MaxiCode m odes.

  • Page 168: Mo De 0 (Obsolete) Sam Ple

    Weight (lb.) C,"1 5~029" | Address validation C,"Y~0 29" | Street address (empty) C,"6 0 SADDLEB ROOK CT.~0 29" | City (empty) C,"DAYTON~029 " | State C,"OH~030" | C,"~004" | } A-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 169: Mode 2 Sample

    C,"~029" | Package count C,"1 /1 ~029" | Weight (lb.) C,"1 0~029" | Address validation C,"Y~0 29" | Street address (empty) C,"~029" | City (empty) C,"~029" | State C,"CT~030" | C,"~004" | } Classification: Avery Dennison – Public Samples A-9...

  • Page 170: Mode 3 Sample

    C,"1 0~0 29 " | Address validation C,"Y~02 9 " | Street address (empty) C,"~02 9 " | City (empty) C,"TORONTO~02 9" | State C,"ON~0 30" | C,"~00 4 " | } A-10 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 171: Ma Xicode Com Pres Sion Sample

    Batch data c an also be included as one long s tring without c arriage return or line feed (CRLF) charac ters. {B ,1,N,1| 1,"[)>~03 001~0299614201 0000~029 840 ~0 29003~02 91Z00 000014~029UPSN~029111111~03 007#P36 (AWO'$6 ,X3& W6 HMJ AL-7WK0 8 YU,)92+'#I%~029#S~013~030~004"|} Classification: Avery Dennison – Public Samples A-11...

  • Page 172: Sample Ms I Packet

    , and test tubes . Refer to the AIM International Sy mbology Spec ification for m ore details about data requirem ents. A-12 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 173: Sample Qr Code Pac Ket

    {F,25 ,A,R,E,200,2 00,"Fmt 25 " | C,14 0,40 ,0,1 ,2,1,W,C,0,0,"SAMPLE FORM AT" | B ,1,12,F,85,40,1,2,40,5 ,L,0 | T,2 ,1 8,V,50,50,1,3,1,1,B,L,0,0 | } Sample Batch Packet {B ,25,N,1 | 1,"02 802811111" | 2,"TEXT FIELD" | } Classification: Avery Dennison – Public Samples A-13...

  • Page 174: Sample Data Entry Form At Pac Ket (Upca Bar Code)

    R,5 ,N | C,30,10,0,1,1,1,B,L,0,0,"MADE IN USA",0 | L,S,11 0,30,110,150,10," " | Q,240,30,270,150,3," " | } Depending on the operator-entered batc h data, a label s imilar to this one prints . A-14 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 175: Sample Rfid Data Fields

    2,"31 32 333435363738393031 32" |} ASCII HEX Incrementing Field {F,2,A,R,E,400,400,"ASCIIHEX" | T,1 ,5 0,V,10,10,0,1,1,1,B,L,0,0 | X,2 ,2 4,0 | R,6 0,I,1 |} {B ,2,N,5 | 1,"31 32333435363738393 03132" | 2,"31 32333435363738393 03132" | } Classification: Avery Dennison – Public Samples A-15...

  • Page 176: Sscc96

    C,11 0,38 5,0,50,6,6,B,L,0,2,"SHIP TO RFID USER" | C,11 0,15 0,0,50,6,6,B,L,0,2,"CARRIER" | C,150,15 0,0,50,9,9,B,L,0,2,"PRO:" | C,16 5,15 0,0,50,9,9,B,L,0,2,"B/L:" | C,20 0,38 0,0,50,18,15,B,L,0,2,"AVERY DENNISON" | C,23 5,38 0,0,50,14,12,B,L,0,2,"EMAIL: RFID@MONARCH.COM" | C,25 5,38 0,0,50,14,12,B,L,0,2,"PHONE: 1 8 00 54 3-6650" | C,27 5,34 5,0,50,6,6,B,L,0,2,"VENDOR STK NO:" | C,27 5,11 0,0,50,6,6,B,L,0,2,"PACK/UNITS:"...

  • Page 177: Sgtin 96

    C,11 0,38 5,0,50,6,6,B,L,0,2,"SHIP TO RFID USER" | C,11 0,15 0,0,50,6,6,B,L,0,2,"CARRIER" | C,15 0,15 0,0,50,9,9,B,L,0,2,"PRO:" | C,16 5,15 0,0,50,9,9,B,L,0,2,"B/L:" | C,20 0,38 0,0,50,18 ,15,B,L,0,2,"AVERY DENNISON" | C,23 5,380,0,50,14,12,B,L,0,2,"EMAIL: RFID@MONARCH.COM" | C,25 5,38 0,0,50,14,12,B,L,0,2,"PHONE: 1 8 00 54 3-6650" | C,27 5,34 5,0,50,6,6,B,L,0,2,"VENDOR STK NO:" | C,27 5,11 0,0,50,6,6,B,L,0,2,"PACK/UNITS:"...

  • Page 178: Password Lock

    The RFID data field inc ludes zeroes s o the field's m aximum number of charac ters is 96 bits of data (24 ASCII Hex charac ters ). The encoded RFID data contains the first 58 bits of provided EPC data and 38 bits of the calc ulated serial number. A-18 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 179: Fonts

    The CG Triumvirate™ typefac es s upport only ANSI and DOS Code Page 437 and 850 Sym bol Sets . The scalable font does not support Code Page 1256 (Arabic). The Euro symbol( ) at position ~192 is only available in the Standard, Reduced, and Bold fonts . Classification: Avery Dennison – Public Fonts B-1...
  • Page 180 These samples were printed using the Internal Sym bol s et. Standard Font Re duce d Font Bold Font OCRA-like Font EFF Swiss Bold Font* * P rinted w ith A N S I S y mbol S et B-2 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 181 These s amples were printed us ing Code Page 437. CG T riumv irate ™ T ype face Bold CG T riumv irate ™ T ype face Classification: Avery Dennison – Public Fonts B-3...

  • Page 182: Paxarsymbols Font 56 Characters

    Use the tilde sequenc es shown in this table to produc e the desired c haracter on tags/labels. {F,1,A,R,E,200,200,"Font7 0" | T,1 ,1 0,V,25,25,0,70,2,2,B,L,0,0| T,2 ,1 0,V,65,65,0,70,1,1,B,L,0,0|} {B ,1,N,1| 1,"~04 2 ~064"| 2,"~052 ~05 4"|} B-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 183: Nafta Font 72 And Font 73 Character

    Pr of es s ional Do Not Dr y Dr y c lean, Heat Heat dr y c lean c lean A ny Solv ent Heat, No Heat, No Heat, No Steam Steam Steam Classification: Avery Dennison – Public Fonts B-5...

  • Page 184: Bitmap Font In Form Ation

    Hex or Run-Length enc oding for the printer. Select the point s ize and c haracters to print. Bitmap fonts m ay im age faster than a TrueType font, but they are limited to the downloaded point siz e and c haracters. B-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 185: Mo Nospaced Font Magn Ification

    Maximum) by the magnific ation. Exam ple 13 (Average font dots ) x 5 (magnification) = 65 dots in an average letter of the CG Trium virate™ Typeface Bold at 5x. Classification: Avery Dennison – Public Fonts B-7...

  • Page 186: Scalable Font Information

    Save the fonts to flash memory for optimal performance with downloaded fonts. No m em ory configuration packets are necess ary sinc e flas h memory cannot be realloc ated. B-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 187: Using Internat Ional F Onts

    * Charac ters in batch data m us t be entered bas ed on their mapping (Unic ode, BIG5, etc.). Note : Symbol s ets 102-110 require a downloaded International TrueType font. Classification: Avery Dennison – Public Fonts B-9...

  • Page 188: Inter Nation Al Font Sample

    L i c e n s in g F o n ts Avery Dennison provides tools to create and download TrueType fonts. However, it is your responsibility to purchase and licens e any fonts you download to the printer. Contac t a font supplier for licensing inform ation.

  • Page 189: Symbol Sets/Code Pages

    U s in g Co d e 1 2 8 F u n c t io n Co d e s This table lists the c haracters for Bar Code 128 function codes . These func tions are used with sc anners . Code Function Code ~201 ~202 ~203 ~204 Classification: Avery Dennison – Public Symbol Sets/Code Pages C-1...

  • Page 190: Entering Extend Ed Characters

    For exam ple, to produce the ™ character with the Internal character s et, press Alt 255 (c olumn 15 + row 240) or us e ~255 in the data s tream . C-2 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 191 ANSI Symbol Set Bold Symbol Set OCRA Symbol Set Code Page 100 (Macintosh) Code Page 101 (Wingdings) Code Page 437 (Latin U.S.) Code Page 850 (Latin 1) Code Page 852 (Latin 2) Code Page 855 (Russian) Code Page 857 (Turkish) Note: To determine the character code, add the column number and row number for the character.
  • Page 192 Code Page 860 (Portuguese) Code Page 1250 (Latin 2) Code Page 1251 (Cyrillic) Code Page 1252 (Latin 1) Code Page 1253 (Greek) Code Page 1254 (Turkish) Code Page 1255 (Hebrew) Code Page 1256 (Arabic) Code Page 1257 (Baltic) Code Page 1258 (Vietnamese) Note: To determine the character code, add the column number and row number for the character.

  • Page 193: Ascii T O He Xadecim Al Convers Ion Chart

    He x De cimal Char. He x De cimal Backspace Esc ape Linefeed File s eparator Vertical tab Group separator Form feed Record s eparator Carriage Unit s eparator return Space „ Classification: Avery Dennison – Public Symbol Sets/Code Pages C-5...
  • Page 194 Char. He x De cimal Char. He x De cimal < & ‚ > ‚ C-6 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 195 ASCII to Hexadecimal Conversion Chart (continued) Char. He x De cimal Char. He x De cimal Delete Classification: Avery Dennison – Public Symbol Sets/Code Pages C-7...
  • Page 196 C-8 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 197: Format Design Tools

    Use copies of these worksheets and grids to c reate online configuration pac kets and design form ats : ♦ Online Configuration W orksheet ♦ Supply Layout Grids (English, Metric, Dots ) Classification: Avery Dennison – Public Format Design Tools D-1...

  • Page 198: Online Configurati On W Orks Heet

    O n l i n e C o n f i g u r a t i o n W o r k s h e e t D-2 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 199: Supply La Yout Gr Ids (English)

    S u p p l y L a y o u t G r i d s ( E n g l i s h ) Classification: Avery Dennison – Public Format Design Tools D-3...

  • Page 200: Supply La Yout Gr Ids (Me Tric)

    S u p p l y L a y o u t G r i d s ( M e t r i c ) D-4 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 201: Supply La Yout Gr Ids (Dots)

    S u p p l y L a y o u t G r i d s ( D o t s ) Classification: Avery Dennison – Public Format Design Tools D-5...
  • Page 202 D-6 Packet Reference Manual Classification: Avery Dennison – Public...

  • Page 203: Glossary

    All characters have the s am e width and are eas y to center jus tify. (Standard, bold, and reduced are monospaced.) Non-v olatile RAM Contains information that is SAVED when the printer is turned off. Classification: Avery Dennison – Public Glossary G-1...
  • Page 204 Contains information that is LOST when the printer is turned off. Write Powe r Increas e or decreas es the s trength of the RF field emitted by the printer’s antenna to program the RFID inlays. G-2 Packet Reference Manual Classification: Avery Dennison – Public...
  • Page 206 AMERICAS 170 Monarch Lane Miamisburg, OH 45342 937 865 2123 (direct) Tel +800 543 6650 (8:00 a.m. – 6:30 p.m., EDT) Fax +937 865 6663 ASIA No. 7 Chun Ying Street Tseung Kwan O Industrial Estate New Territories, Hong Kong Tel +852 2372 3169 Fax +852 2995 0014 WESTERN EUROPE...

Table of Contents
