- Page 1 Fixed Formats User Manual User Manual TC6032FFUM Rev. AE 3/08 Pathfinder Ultra SALE 58523 32232 $25.00 97896 52341 MENS SHIRT SMALL $26.33 ©2006 Paxar Americas, Inc. a subsidiary of Avery Dennison Corp. ® Monarch ® ® Silver Printer All rights reserved.
-
Page 3: Table Of Contents
T A B L E O F C O N T E N T S INTRODUCTION Entering Data ... 1-2 Using the Keypad ... 1-2 Using Function with Number Keys ... 1-3 Data Entry Modes ... 1-4 Entering Letters ... 1-5 Correcting Data Entry Errors ... - Page 4 USING THE FORMATS Format 1: UPCA Price Format ... 3-1 Format 2: UPCA + Price CD Format ... 3-2 Format 3: 2 Line/Price Format... 3-3 Format 4: UPCA Only Format ... 3-4 Format 5: 3 Line/Price Format... 3-5 Format 6: UPCA Price Format with Description ... 3-6 Format 7: UPCA + Price CD (w/Description) Format ...
-
Page 5: Introduction
I N T R O D U C T I O N Your Pathfinder® Ultra® Silver 6032™ printer is loaded with 10 fixed formats. This manual describes each format and the data that will print on your label/tag. Information in this document supercedes information in previous versions. -
Page 6: Entering Data
♦ data entry modes ♦ upper-case letter entry ♦ data entry error correction. Using the Keypad The printer keypad appears below. Key(s) Description Enter Accepts data or a menu selection. Ctrl For future use. Displays a special character when pressed with a 3-digit number. -
Page 7: Using Function With Number Keys
Moves between items in a menu or characters in a line. Depending on the situation, the right arrow can act as a down arrow. The left and up arrows can also be the same. On/Off Turns the printer on and off. Space Enters a space character. Numeric/ Displays a numeric digit or upper-case letter. -
Page 8: Data Entry Modes
Key(s) Description (continued) Set Input Mode Contrast (Use arrow keys to scroll, Enter to set) Recall Data Data Entry Modes There are three data entry modes: ♦ Normal (Numeric) mode – Default. Press the key to access what appears on the face of the key (numbers). ♦... -
Page 9: Entering Letters
C, press 7 three times. Press the keys quickly. If you pause too long between key presses, the printer assumes you have entered the letter you need and the cursor moves one space to the right. Correcting Data Entry Errors If you make a mistake as you enter data, you can do two things. - Page 10 1-6 Fixed Formats User Manual...
-
Page 11: Getting Started
This chapter provides an overview of how to print labels/tags and explains the special functions provided with the Fct key. O v e r v i e w To start printing formats: Turn on the printer. A screen similar to the one below appears briefly. Standard - 1211 P:124224 V:3.0 You see the menu entry for the format last printed. -
Page 12: Using Special Functions
♦ turn the backlight on or off. Selecting a Print Method You must choose a print method so the printer can print the labels in the manner you want. The choices are ♦ Print 1 Label ♦... -
Page 13: Changing Dates
Format menu. Changing Dates You can change the system date at any time while using the printer. Press Fct-2, and the date entry prompt will appear. Turning the Backlight On or Off The backlight enables you to see the display a little better if your lighting conditions are poor. - Page 14 2-4 Fixed Formats User Manual...
-
Page 15: Using The Formats
Scan a bar code or enter 11 numeric digits (leaving one asterisk on the display unused). DEPT ? Enter up to 4 characters. PRICE ? Enter up to 5 numeric digits. The printer lists the system date (for example: 04/18/02). UPC A Bar Code Department Using the Formats 3-1... -
Page 16: Format 2: Upca + Price Cd Format
(5604) and characters 7-11 is the department (75120). If you enter less than the maximum number of digits in either field, the printer zero-pads the data from the left in the bar code. ♦ Character 6 is also a check digit (in addition to character 1). -
Page 17: Format 3: 2 Line/Price Format
F o r m a t 3 : 2 L i n e / P r i c e F o r m a t Description Line 1 Description Line 2 Price Prompt What You Do LINE 1 ? Enter up to 10 characters. LINE 2 ? Enter up to 10 characters. -
Page 18: Format 4: Upca Only Format
F o r m a t 4 : U P C A O n l y F o r m a t Prompt What You Do Scan a bar code or enter 11 numeric digits (leaving one UPC-A ? asterisk on the display unused). 3-4 Fixed Formats User Manual UPC A Bar Code... -
Page 19: Format 5: 3 Line/Price Format
F o r m a t 5 : 3 L i n e / P r i c e F o r m a t Description Line 1 Description Line 2 Description Line 3 Price Prompt What You Do LINE 1 ? Enter up to 14 characters. -
Page 20: Format 6: Upca Price Format With Description
Scan a bar code or enter 11 numeric digits (leaving one asterisk on the display unused). DEPT ? Enter up to 4 characters. PRICE ? Enter up to 5 numeric digits. The printer lists the system date (for example: 04/18/02). 3-6 Fixed Formats User Manual UPC A Bar Code Department... -
Page 21: Format 7: Upca + Price Cd (W/Description) Format
(2495) and characters 7-11 is the department (75120). If you enter less than the maximum number of digits in either field, the printer zero-pads the data from the left in the bar code. ♦ Character 6 is also a check digit (in addition to character 1). -
Page 22: Format 8: Ean8 Price Format
DEPT ? PRICE ? Enter up to 5 numeric digits. Notes ♦ The printer lists the system date (for example: 04/18/02). ♦ The bar code’s right-most character is the check digit. 3-8 Fixed Formats User Manual E AN-8 Bar Code... -
Page 23: Format 9: Upce Price Format
Enter up to 4 characters. DEPT ? PRICE ? Enter up to 5 numeric digits. Notes ♦ The printer lists the system date (for example: 04/18/02). ♦ The bar code’s check digit does not appear. UPCE Bar Code Department Using the Formats 3-9... -
Page 24: Format 10: Upca Sale Price Format
F o r m a t 1 0 : U P C A S a l e P r i c e F o r m a t Fixed Field UPC A Bar Code Price Prompt What You Do Scan a bar code or enter 11 numeric digits (leaving one UPC-A ? asterisk on the display unused). - Page 26 Visit www.monarch.com for sales, service, supplies, information, and telephone numbers for our locations throughout the world. TOLL FREE: 1-800-543-6650 (In the U.S.A.) 1-800-363-7525 (In Canada)
