Operating
Operating
®
Monarch
Instructions
Instructions
932™ Stacker
TC0932OI Rev. AC 12/07
©2004 Paxar Americas, Inc. a subsidiary of Avery Dennison Corp. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stacker Monarch 932TM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avery Dennison Stacker Monarch 932TM

Summary of Contents for Avery Dennison Stacker Monarch 932TM

  • Page 1 Operating Operating ® Monarch Instructions Instructions 932™ Stacker TC0932OI Rev. AC 12/07 ©2004 Paxar Americas, Inc. a subsidiary of Avery Dennison Corp. All rights reserved.
  • Page 2 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Paxar Americas reserves the right to make changes in the product, the programs, and their availability at any time and without notice.

  • Page 3: Table Of Contents

    Installing the Stacker ..........1-1 Step 1 - Installation for the 9860 Printer ..... . . 1-2 Step 2 - Level the Stacker .
  • Page 4 ii Table of Contents...

  • Page 5: Getting Started

    G E T T I N G S TA R T E D The Monarch® 932 stacker works with a Monarch® 9860 printer. The stacker supports backfeed mode on the printer. There is no power ON/OFF switch for the stacker. Once the stacker is plugged into an outlet, it is on.

  • Page 6: Step 1 - Installation For The 9860 Printer

    S t e p 1 - I n s t a l l a t i o n f o r t h e 9 8 6 0 P r i n t e r 1. Locate the screw hole on the stacker mounting plate. Flanged screw Adjusting Bracket...

  • Page 7: Step 2 - Level The Stacker

    S t e p 2 - L e v e l t h e S t a c k e r 1. Check the distance between the rollers and the knife. Make sure the rollers are not touching the front of the knife or too far from the knife.

  • Page 8: Step 3 - Connect The Power Cord

    S t e p 3 - C o n n e c t t h e P o w e r C o r d 1. Plug the power cord into the stacker’s AC inlet. 2. Plug the other end of the power cord into a grounded outlet. Once the power cord is attached to an outlet, the stacker is on.

  • Page 9: Step 4 - Check The Alignment

    S t e p 4 - C h e c k t h e A l i g n m e n t 1. Load supply in the printer. For more information about loading supply, refer to the printer’s Operator’s Handbook or Quick Reference.
  • Page 10 Transport Lock 6. Make sure the transport lock handle is in the locked position. 7. Make sure supply is loaded and the printer is turned on. 8. Press the Feed or Cut button on the printer or keyboard several times.

  • Page 11: Step 5 - Set The Tag Width

    9. Use the cut tags as a guide and adjust the guide rails back into the grooves so that they are barely touching the sides of the tag. S t e p 5 - S e t t h e Ta g W i d t h 1.

  • Page 12: Step 6 - Set The Belt Speed

    5. Tighten the knob. 6. Place the tag weight against the tag stop. 7. Print a test batch of 50 tags. The stacker’s LED is on when tags are moving through the stacker. S t e p 6 - S e t t h e B e l t S p e e d . 1.
  • Page 13 3. Turn the belt adjustment knob to the number from the stack. Belt Adjustment Knob 4. Print another test batch of 50 or more. The stacker’s LED is on when tags are moving through the stacker. Look at how the tags sit in the stacker tray. If the tags are too: Tight, turn the belt speed to a higher setting (higher number).
  • Page 14 1-10 Getting Started...

  • Page 15: How To Operate

    H O W T O O P E R AT E This chapter describes how to re-load and change supplies empty the stacker tray clear a tag jam install verifier riser blocks How to Operate 2-1...

  • Page 16: Re-Loading Or Changing Supplies

    R e - L o a d i n g o r C h a n g i n g S u p p l i e s If you run out of supplies while printing, the printer display or keyboard shows a 756 status code.

  • Page 17: Stacker Running

    3. Continue to remove tags. C l e a r i n g a Ta g J a m If a tag jams inside the stacker, the printer and stacker automatically stops. The printer display or keyboard shows a 761 status code.

  • Page 18: Installing Riser Blocks

    I n s t a l l i n g R i s e r B l o c k s Install riser blocks as shown when using a printer and stacker with a verifier. Make sure stacker feet seat securely in the riser blocks.

  • Page 19: Troubleshooting

    Stacker does not Make sure the stacker is turned on and is properly work. connected to the printer. See Chaper 1, "Getting Started" for more information. Tags are stacked Empty the stacker tray. Turn the adjustment knob to a lower too loosely.
  • Page 20 3-2 Troubleshooting...

  • Page 21: Specifications

    S P E C I F I C AT I O N S S t a c k e r Height: 14 inches (355.6 mm) Depth: 7.9 inches (201 mm) Base Width: 24 inches (609.6 mm) Tag Bed: 29.6 inches long (752 mm) Weight: 18 lbs.

  • Page 22: Supplies

    S u p p l i e s Thickness: Widths: Lengths: M i n i m u m S t a c k e d Ta g D i m e n s i o n s If a tag is printed width wise: If a tag is printed length wise:...
