4.3.3

Setting up the MDA

8020065-ZLP4/2017-08-10|SICK
Subject to change without notice
The Master Data Analyzer is set up on a table.
WARNING
Risk of injury due to the device tipping over
There is a risk of the MDA tipping over during installation. An unsuitable surface may also
lead to the device tipping over.
The device tipping over can lead to the severe crushing or even loss of limbs.
There is also the risk of inflicting damage to the device.
Measures
▸
Place the device on a sufficiently stable and steady table.
▸
Secure the table to prevent rolling away.
▸
All four of the adjustable feet must be completely on the table.
WARNING
Risk of crushing when settings down the MDA
The adjustable feet are designed so that the safety distance between the bottom of the
device and the tabletop can be observed.
There is a risk of crushing when installing the MDA on the tabletop.
Measures
▸
Do not put your hands under the base of the housing when installing the MDA.

Fig. 27: Risk of crushing when settings down the MDA
