  • Page 1 Main A D D E N D U M T O O P E R A T I N G I N S T R U C T I O N S FLOWSIC100 Flare FLSE100-XT sender and receiver units: Description...
  • Page 2 NOTICE Hazard which could result in property damage. Information symbols Important technical information for this product Supplementary information Link referring to information at another place FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 3: Table Of Contents

    Nozzle installation tool ........... . 36 4.6.3 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 4 Accessories for FLSE100-XT sender/receiver units ......84 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 5 Standards compatibility and type approval ........86 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 6 Cont ents FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 7: About This Document

    About this document FLOWSIC100 Flare About this document Function of this document Scope of application Target groups Data integrity Further information FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 8: Function Of This Document

    In all cases, the customer is responsible for the implementation of safety measures suitable for the respective situation, e.g., network separation, firewalls, virus protection and patch management. Further information 1 . 5 NOTICE: Observe all supplied documents. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 9: For Your Safety

    Main hazards Retraction mechanism of the sender/receiver units Operation in potentially explosive atmospheres Warning information on device Requirements on the personnel's qualification Restrictions on use FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 10: Basic Safety Information

    Intended use 2 . 2 FLSE100-XT sender/receiver units may only be used to measure the gas velocity, gas volume, mass flow and molecular weight in pipelines. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 11: Main Hazards

    XT sender/receiver units specified for such use ( p. 13, §2.5). ▸ Observe the information on  p. 11, §2.3.1 during installation work on running equipment (“hot tapping” method). FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 12: Hazards Through Electrostatic Discharges

    This connection is closed with a dummy plug at the factory. ▸ The dummy plug may only be removed when a venting valve is installed,  p. 60, §4.10. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 13: Operation In Potentially Explosive Atmospheres

    Ex db [ia Ga] IIA T4 Ga/Gb Cl I, Div2 Group A, B, C, D T4; Cl I, Zone 2 Ex/AEx nA [ia] IIC, T4 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 14: Specific Conditions

    -50 °C – Ambient pressure 80 kPa (0.8 bar) to 110 kPa (1.1 bar) – Air with normal oxygen content, typically 21 percent by volume. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 15: Temperature

    … +195 °C -196 … +70 °C -50 … +70 °C -196 … +280 °C -196 … +70 °C -50 … +70 °C For F1F-H: -70 °C FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 16: Warning Information On Device

    – Degree of protection – Fitting instructions – Area definition ▸ Regulations to be applied: – IEC 60079-14 – IEC 60079-17 or comparable national regulations. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 17: Restrictions On Use

    Leak tightness is to be checked regularly during operation and the seal replaced, as required. ● Before every re-installation new seals have to be used in the required design. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 18 Zone 0. The wall must be thicker than 3 mm. The requirements in EN 60079-26 Section 4.6 must be adhered to. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 19: Product Description

    Product description FLOWSIC100 Flare Product description Product identification Sender/receiver units Material for parts with process gas contact Spool piece option Transport and storage FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 20: Product Identification

    Example of marking plate passive (SLAVE) FLSE100-XT-S (ATEX/IECEx) Fig. 2 Type plate example FLSE100-XT-M Example of marking plate FLSE100-XT-M (ATEX/IECEx) Example of marking plate passive (SLAVE) FLSE100-XT-M (ATEX/IECEx) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 21 Example of marking plate FLSE100-XT-H (ATEX/IECEx) Example of marking plate passive (SLAVE) FLSE100-XT-H (ATEX/IECEx) Fig. 4 Type plate example FLSE100-XT-P Example of marking plate FLSE100-XT- (ATEX/IECEx) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 22: Sender/Receiver Units

    2 Electronics unit Duct probe 3 T-connector Sensor contour 4 TNC connector (connection for Slave) Transducer 5 Self-cutting ring 10 TNC connector (connection for Master) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 23 1 Pressure compensation element 5 Retraction nozzle 2 Electronics unit 6 Duct probe 3 Cable gland (connection for Slave) 7 Sensor contour 4 Self-cutting ring 8 Transducer FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 24 1 Pressure compensation element 6 Retraction nozzle 2 Electronics unit 7 Duct probe 3 T-connector 8 Transducer 4 Pressure compensation element 9 Sensor contour 5 Self-cutting ring FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 25: Material For Parts With Process Gas Contact

    12 Sensor contour, probe version F1F-P 5 Retraction nozzle 13 Transducer holder within sensor contour 6 Connecting flange 14 Adjusting ring 7 Transducer 15 Thrust ring 8 Sensor contour FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 26: Spool Piece Option

    Spool piece option 3 . 4 The FLOWSIC100 Flare can also be fitted with an optional spool piece to reduce geometric uncertainty of device installation and to simplify assembly. The exact design (nominal diameter, connection, material) always depends on the customer specifications.

  • Page 27: Special Notes For Handling The Spool Piece Option

    ▸ During transport, the spool piece must not be turned over or start to swing. Fig. 12 Lifting requirements Max. 60 ° FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 28 Product description FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 29: Installation

    Pulling the sender/receiver units back Fitting the sender/receiver units Pulling the sender/receiver units back Fitting the venting valve Fitting the weatherproof cover for the sender/receiver units FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 30: Safety Information

    To ensure safe and reliable operation of the measuring devices, ensure that the current operating conditions on the system correspond to the specifica- tions on the type plates of the sender/receiver units. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 31: Fitting The Spool Piece (Option)

    Install the pressure measurement line between the pressure tapping point (option) and the pressure sensor (option). ▸ Perform a leak tightness check with suitable means after completion of the installation work, p. 58, §4.8.4. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 32: Installation Sequence

    – Nozzle angle – For cross-duct versions additionally: Transducer distance a ● Geometric installation parameters for commissioning of the measuring system,  p. 48, §4.8.1. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 33: Installation Accessories

    It must be ensured that the temperature of the nozzle and ball valve is not so high that the material strength can no longer be guaranteed when derating the pressure over the temperature,  p. 79, §7.3. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 34: Nozzles, Blind Flanges And Seals

    Table 5 Available seals Material Temperature range Grooved metal gasket B9A 1.4571 -196 … +280°C FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 35: Ball Valve

    (-50...+392°F) Low temperature -196...+200°C Ball valve Stainless steel 1.4408 (-320...+392°F) (CF08M) High temperature -50...+400°C Ball valve PN40 DN50 PN40 DN50 Stainless steel 1.4408 (-58...+752°F) (CF08M) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 36: Nozzle Installation Tool

    Installation Nozzle installation tool 4.6.3 The installation tool serves to align and weld the nozzle on the pipeline. SICK offers various nozzle installation tools depending on the nominal pipe diameter and path configuration. The nozzle installation tool contains, per nozzle ●...

  • Page 37: Fitting The Nozzles On The Pipeline (Measuring System Without Spool Piece)

    3) Loosen the fastening, take the strip off and lay it out on a level surface. For 1-path measurements, fold the strip to the overlap line so that the part matching pipe circumference (U) is halved. Overlap line FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 38: Determine The Nozzle Position For Cross-Duct Versions

    U    ----------------------------- -  77 5   0 8    U    ----------------------------- - 4 5107  FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 39 5) Draw guide lines (1) for the nozzle positions with the previously calculated nozzle offset a, mark crossing points (2) and draw marking points (3) in distance 60 mm (x) from the crossing points. U / 2 Path 1 Path 2 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 40 Path 1 Path 2 7) Take the strip off again and join the additional markings with a line. Marking lines Marking lines FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 41: Determining The Nozzle Position For The Probe Version

    5) Draw a guide line (1) for the nozzle position(s), mark crossing points (2) and draw marking points (3) in distance 60 mm (x) from the crossing points. Path 1 Path 2 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 42: Welding The Nozzle On

    A faulty welding seam can allow gas to escape from the pipeline. This can ▸ Ensure welding seams are gas-tight. ▸ Check strength and durable tightness of the welding seams. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 43 ▸ Place the centering (7) into the nozzle opening so that the marking on the centering corresponds to the nozzle type (ANSI or DIN, size). FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 44 – On cross-duct versions, weld the nozzle on the opposite pipeline side in the same manner and then determine distance D2. – Note measures D1 and D2; these measures are required for the geometric calculation during commissioning. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 45 ( p. 37, §4.7). ▸ Only once on each nozzle. ▸ Have this work done by skilled persons specially qualified for this work. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 46: Drilling Holes Into The Pipeline If Plant Is In Operation (Hot Tap)

    Keep the ball valve closed and fitted until a sender/receiver unit has been fitted. ▸ Secure the ball valve against unintentional activation. ▸ Instruct other persons accordingly. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 47: Fitting The Sender/Receiver Units

    Overview 1 Electronics unit 5 Mounting kit 2 Duct probe 6 Ball valve 3 Cutting ring screw connection 7 Nozzle 4 Retraction nozzle 8 Pipeline FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 48: Calculating The Wetted Part Length Wl And Geometric Installation Parameters

    5 For cross-duct versions, enter the "Transducer distance" a determined during nozzle installation, p. 38, §4.7.2 . 6 Enter the required dimensions: – Circumference U FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 49 Fig. 27 Installation of F1F-S, F1F-M, F1F-H (cross-duct versions) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 50 Installation Fig. 28 Installation of F1F-P (probe version) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 51: Calculating The Wetted Part Length For Cross-Duct Versions

    WallThickness [mm] = Wall thickness of pipe FittingAdjust [mm] = 1 mm Compensation when tightening the self-cutting ring fitting (self-cutting ring fitting displaces the duct probe by 1 mm when tightened) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 52: Calculating The Wetted Part Length For The Probe Version

    0,966 = sin(75°) – Nominal nozzle installation angle FittingAdjust [mm] = 1 mm Compensation when tightening the self-cutting ring fitting (self-cutting ring fitting displaces the duct probe by 1 mm when tightened) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 53 FittingAdjust [mm] = 1 mm Compensation when tightening the self-cutting ring screw fitting (self-cutting ring fitting displaces the duct probe by 1 mm when tightened) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 54: Tightening The Self-Cutting Ring

    Positioning of self-cutting ring (overview) Wetted part length wL 1 Cap nut (self-cutting ring fitting) 2 Marking of self-cutting ring fitting 3 Pipe screw fitting 4 Duct probe FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 55 7 Completely loosen the pipe screw fitting. 8 Loosen the cap nut again and fully retract the sender/receiver unit for transport to and installation into the pipeline. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 56: Installing Sender/Receiver Units

    Observe when aligning the probe version Align probe version F1F-P correctly before securing the self-cutting ring fitting again: FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 57 Tighten the self-cutting ring fitting 1.25 turns after alignment. Make sure the markings for the self-cutting ring fitting are next to each other again, → Fig. 32. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 58: Leak Tightness Check

    1 Completely loosen the cap nut of the self-cutting ring fitting, → Fig. 36. 2 Completely loosen the pipe screw fitting, → Fig. 36. 3 Pull the sender/receiver unit back completely to the stop. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 59 1 Cap nut (self-cutting ring fitting) 2 Pipe screw fitting WARNING: Hazardous gas (possibly explosive or toxic) Consider the gas trapped in the retraction nozzle,  p. 12, §2.4. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 60: Fitting The Venting Valve

    4 . 1 0 A venting valve is available as an option from SICK (Order No. 2108210). Use a suitable valve with 1/8" NPT thread when the valve available from SICK is not used. WARNING: Hazard through gas in the pipeline ▸...

  • Page 61: Fitting The Weatherproof Cover For The Sender/Receiver Units

    Overview 4.11.1 Fig. 38 Weather protection overview 1 Holder 2 Safety splints 3 Weatherproof cover 4 Washers 5 Hexagon nuts 6 Round steel bow FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 62: Fitting The Weatherproof Cover

     Make sure the holder is correctly aligned. See the adjacent Figure. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 63 Installation 2 Push the weatherproof cover into the holder. 3 Fix the weatherproof cover with the four safety splints. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 64 Installation FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 65: Electrical Installation

    Electrical installation FLOWSIC100 Flare Electrical installation General instructions, prerequisites Cable specifications Cable glands Requirements for installation in the Ex zone Connection diagrams FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 66: General Instructions, Prerequisites

    F1F-H. Only use installation material approved for the applied hazard zone. The user is responsible for correct selection. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 67: Requirements For Installation In The Ex Zone

    For this reason, the associated connection cable FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 68 “Exi” or a blue cable covering or with blue shrink sleeves on the cable ends or with the SICK item number, at least on the associated packaging. The technical safety data are shown in the Type Examination Certificate.

  • Page 69: Connection Overview

    Communication between FLSE Master and a higher level control system (Interface 1) MCX: Signal for FLSE Slave NOTICE: Self-locking terminals for wire sizes 0.5 .. 1.5 mm² (AWG20 ... AWG16). FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 70: Connection Diagrams

    +24 V DC RS485a yellow RS485b Terminals Connection cable FLSE100 Slave +24 V DC FLSE100-XT (passive RS485a ultrasonic transducer * RS485b *: Not for FLSE100-XT-P FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 71: Commissioning

    Commissioning FLOWSIC100 Flare Commissioning General information Commissioning procedure FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 72: General Information

    FLOWSIC100 Flare measuring system. Commissioning procedure 6 . 2 For commissioning follow the instructions in the Operating Instructions FLOWSIC100 Flare §4 "Start-up and Parameter Settings". FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 73: Technical Data

    Technical data FLOWSIC100 Flare Technical data FLSE100-XT sender/receiver units Application limits Derating of pressure resistance Dimension drawings FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 74: Flse100-Xt Sender/Receiver Units

    Cl I, Zone 2, Ex/AEx nA [ia] IIC, T4 Installation Weight ≤ 12 kg (sensor pair)  p. 79, §7.3  »Derating of pressure resistance« Temperature dependent, details see FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 75: F1F-M

    Cl 1, Zone 2, Ex/AEx nA IIC, T4 Installation Weight ≤ 14 kg (sensor pair)  p. 79, §7.3  »Derating of pressure resistance« Temperature dependent, details see FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 76: F1F-P

    Cl I, Zone 2 Ex/AEx nA [ia] IIC, T4 Installation Weight ≤ 10 kg  p. 79, §7.3  »Derating of pressure resistance« Temperature dependent, details see FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 77: Application Limits

    1-path SOS = 450 m/s 1-path SOS = 650 m/s 2-path SOS = 340 m/s 2-path SOS = 450 m/s 2-path SOS = 650 m/s FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 78 IEC Guide 98-3:2008-09 shows a F1F-S in 1-path, 16" nominal pipe size configuration and assumes a gas temperature of 20 °C, ambient pressure, a typical molecular weight of greater than 27 g/mol. FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 79: Derating Of Pressure Resistance

    F1F-P (CSA) F1F-S (ATEX/CSA) / M (ATEX/CSA) / R (ATEX/CSA) / P (ATEX/CSA) F1F-P (CSA) F1F-S (ATEX/CSA) / M (ATEX/CSA) / R (ATEX/CSA) / P (ATEX) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 80: Dimension Drawings

    7 . 4 F1F-S/-M/-H Fig. 47 5.90 5.90 3.62 3.62 FLSE100-XT Dimensions F1F-S 955.5 F1F-M F1F-H 751.5 F1F-P Fig. 48 5.91 59.37 35.16 24.21 3.62 3.54 60.12 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 81: Spare Parts

    Spare parts FLOWSIC100 Flare Spare parts Recommended spare parts for FLSE100-XT sender/receiver units Accessories (optional) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 82: Recommended Spare Parts For Flse100-Xt Sender/Receiver Units

    Contents: Cover, cover lock, cover insulation, O-ring, spring washer, screws, assembly paste, sealing plugs Recommended spare parts for commissioning Recommended spare parts for 2 years operation FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 83: Accessories (Optional)

    FLOWSIC100 Flare Accessories (optional) Accessories for FLSE100-XT sender/receiver units Further accessory parts (cable screw fittings, ball valves, nozzles, etc.) are available on request from SICK FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...

  • Page 84: Accessories For Flse100-Xt Sender/Receiver Units

    Accessories for FLSE100-XT sender/receiver units 9 . 1 Order No. Description Weather/sun protective cover for electronics of the Master ultra- 2105581 sonic sensor 2108210 Venting/drain valve for ultrasonic sensor FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 85 Annex FLOWSIC100 Flare Annex Compliances of FLSE100-XT sender/receiver units FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 86 ● EN 60079-0:2012, EN 60079-1:2014, EN 60079-7:2015, EN 60079-11:2012, EN60079-15:2010 ● EN 60079-26:2015, EN 60079-28:2015, EN 61326-1:2013 ● EN 61010-1 (Safety requirements for electrical equipment) ● EN 60529: 1991/A1:2000/A2:2013 (IP) FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
  • Page 87 Annex FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V 1-0/2020-05 · © SICK Engineering GmbH...
