8.1.6

Cleaning the IP camera's dust shield housing

8020065-ZLP4/2017-08-10|SICK
Subject to change without notice
Cleaning the internal area
▸
Only use a soft, dry, lint-free cloth to clean the internal housing area.
▸
Carefully vacuum the internal housing area if required.
Mounting the glass panel
1. Carefully place the glass panel back on the four connecting bolts.
2. Re-tighten the four knurled screws.
3. Release the measurement gantry from its fixing.
Performing teach-in
It is recommended that the teach-in is performed once the internal housing area is
opened. Refer to chapter
Regularly clean the IP camera's dust shield housing.
Please observe the cleaning instructions supplied by the camera manufacturer.
MAINTENANCE AND REPAIRS
7.9.2.3 Performing teach-in.
