pair, the client must be set to use one of these MD5 pairs, and the
key must be trusted.
Key ID —The key ID must be a number between 1 and 65532.
Digest Scheme —Choose one of the options from the drop-down list. The available
options are:
MD5 (the default)
SHA1
SHA
MDC2
MDC2
RIPEMD160
MD4
Key Str —The key string must be readable ASCII and between 1 and 16 characters
long.
Click the Submit button: The changes will be reflected in the table of the NTP Symmetric
Keys window, which is displayed after clicking the Submit button.
The key(s) you have set up will now appear as options in the Symmetric Key field in both
the NTP Server screen, and the NTP Peer screen.
