2.10 Configuring NTP
AUTH STATUS : Indicates if the selected reference is using MD5 authentication. "None"
indicates authentication not being used.
LAST : The number of seconds that have expired since this reference was last polled for its
time.
POLL : The polling interval, i.e. how often VelaSync is polling this NTP reference for its
time.
DELAY (ms) : The measured one-way delay between VelaSync and its selected reference.
2.10.8.2 NTP Servers: Adding, Configuring, Removing
To add, configure, or remove an NTP Server:
1.
Navigate to MANAGEMENT > NETWORK: NTP Setup .
2.
The NTP Setup screen appears. The NTP Servers panel displays a list of recognized NTP
servers. Click the GEAR icon in the upper right-hand corner of the NTP Servers panel.
72
ATC : ASCII time code reference
USER : User provided time
LOCL : Local reference (synced to itself)
INIT : NTP on server/peer is initializing
STEP : NTP on server/peer is performing initial synchronization step and restart-
ing
CHAPTER •
2 VelaSync User's Manual Rev. 1
