APPENDIX
5.1

Troubleshooting

This section is intended to assist you with troubleshooting VelaSync.
The WebUI provides status information that can be used to help troubleshoot failure symptoms
that may occur.
Please also consult the OEM documentation for Supermicro™ SuperO
WR which can be found online under:
https://www.supermicro.com/manuals/superserver/1U/MNL-1771.pdf
For Technical Support contact information see "Technical Support" on page 222.
5.1.1 Minor and Major Alarms
Minor Alarm
There are several conditions that can cause the Web UI status lights to indicate a Minor alarm
has been asserted. These conditions include:
Too few GPS satellites, 1st threshold : The GNSS receiver has been tracking less than the
minimum number of satellites for too long of a duration. Refer to "Troubleshooting
GNSS Reception" on page 196 for information on troubleshooting GNSS reception
issues.
Major Alarm
There are several conditions that can cause the Web UI status lights to indicate a Major alarm
has been asserted. These conditions include:
Frequency error : Indicates a jump in the oscillator's output frequency has been detected.
Contact Tech Support for additional information.
1PPS is not in specification : The 1PPS input reference is either not present or is not qual-
ified.
System Sync : A Major alarm is asserted when the Timing System is not in sync (Input ref-
erences are not available and the unit is not in Holdover). Examples of not being synced
include:
192
When the Timing System has just booted-up and has not yet synced to a ref-
erence.
When all input references were lost and Holdover Mode has since expired.
®
