3.3 Managing References
Production dates : Since 2016
Constellations : GPS, Galileo, GLONASS, BeiDou, QZSS
Other characteristics:
Client A-GPS option: Yes
Server A-GNSS option: Yes
Resurvey : Automatic, after being moved and rebooted — can be changed, see "Setting
GNSS Receiver Dynamics" on page 122.
Multi-GNSS reception: Yes, within these permissible settings:
GPS
3.3.2.3 Selecting a GNSS Receiver Mode
When connected to a GNSS antenna that receives a GNSS signal, VelaSync can use GNSS as
an input reference. The factory default configuration allows GNSS satellites to be
received/tracked with no additional user intervention required.
However, there are several user-configurable GNSS settings:
The Receiver Mode function allows the GNSS receiver to operate in either a stationary
mode (" Standard " or " Single Satellite " modes), or in a mobile mode environment e.g., in
120
Galileo GLONASS Beidou
X X –
X X X
X X –
X – X
X – –
– X X
– X –
– – X
Note: The augmentation systems SBAS and QZSS can be enabled only if
GPS operation is configured.
–
–
X
–
X
–
X
X
