Web UI Page loc-
ation
HOME page, Sys-
tem Status panel,
Status row
MANAGEMENT/
NTP Setup page
NTP Status Sum-
mary panel
Stratum row
VelaSync User's Manual
Current Status
SYNC indicator is not "lit" VelaSync is in
(not Green).HOLD indic- Holdover
ator is "lit" (Orange).— mode—OR—
OR—FAULT indicator is VelaSync is now
"lit" (Red). Below the Sys- out of Time Sync
tem Status panel there is an
Out of Sync alarm state-
ment
Stratum 15 NTP is not syn-
chronized to its
available input
references
(VelaSync may
have been in
Holdover mode,
but Holdover
has since
expired without
the return of
valid inputs)
Indication Troubleshooting
All available Input References have
been lost. The Reference Status table
on the HOME page will show the cur-
rent status of all inputs (Green is valid
and Red is invalid or not present).
1. Make sure the Input Reference Pri-
ority table still has the desired ref-
erence inputs Enabled, based on the
desired priority. See
Input Reference Priorities" on
page 105
.
2. Make sure the desired input ref-
erences are still connected to the cor-
rect input port of VelaSync.
3. Verify GNSS antenna installation (if
applicable). See
GNSS Reception" on the next
page
.
Note: If VelaSync was just recently
powered-up or rebooted and input ref-
erences are applied, no troubleshoot-
ing may be necessary. Allow at least
10-20 minutes for the input references
to be declared valid and NTP to align
to the System Time (allow an addi-
tional 35-40 minutes for a new install
with GNSS input).
1. Verify in the Configure Reference Pri-
orities table that all available ref-
erences enabled. See
Input Reference Priorities" on
page 105
.
2. Verify that the Reference Status on
the HOME page shows "OK" (Green)
for all available references.
3. Verify NTP is enabled and con-
figured correctly. See
ence Configuration" on page 70
APPENDIX
"Configuring
"Troubleshooting
"Configuring
"NTP Refer-
.
