1.7

The VelaSync Web UI

VelaSync has an integrated web user interface (referred to as "Web UI" throughout this doc-
umentation) that can be accessed from a network-connected computer, using a standard web
browser. The Web UI is used to configure and monitor the unit.
The minimum browser requirements for the Web UI are: Internet Explorer
Firefox
1.7.1 The Web UI HOME Screen
The HOME screen of the VelaSync web user interface ("Web UI") provides comprehensive
status information at a glance, including:
The HOME screen can be accessed from anywhere in the Web UI, using the HOME button in
the Primary Navigation Bar :
The Primary Navigation Bar provides access to all menus:
CHAPTER •
1 VelaSync User's Manual Rev. 1
Note: An integrated Command-Line Interpreter interface (CLI) allows the use of a
subset of commands that are integrated into the Web UI.
® ®
, or Chrome .
Note: Screens displayed in this manual are for illustrative purposes. Actual
screens may vary depending upon the configuration of your product.
vital system information
current status of the references
key performance /accuracy data
major log events .
1.7 The VelaSync Web UI
®
9 or higher,
13
