Spectracom PRISMA VelaSync User Manual page 123

Since both of these references are
added to the Reference Priority table.
Example 2 – IRIG as primary reference, NTP input as backup
In this use case, the objective is to use:
Step-by-step procedure:
1.
2.
3.
Since both of these references are
added to the Reference Priority table.
Example 3 – NTP input as the only available input ("NTP Stratum 2 operation")
In this use case, the objective is to have NTP provided by another NTP server as the only avail-
able reference input, i.e. the unit to be configured is operated as a Stratum 2 server. For more
information, see "Configuring "NTP Stratum Synchronization"" on page 1.
Step-by-step procedure:
1.
2.
3.
Example 4 – Time set manually by the User. Other references may or may not be
available
CHAPTER •
3 VelaSync User's Manual Rev. 1
IRIG as the primary reference input
Another NTP server as backup reference
Move the reference which has "IRIG 0" in both the Time column and "IRIG 0" in the 1PPS
column to the top of the table, with a Priority value of 1. Click the Enabled checkbox.
Move the reference which has "NTP" in the Time column and "NTP" in the 1PPS column
to the second place in the table, with a Priority value of 2. Click the Enabled checkbox.
For all other references, uncheck the Enabled checkbox, so that they are all disabled.
Move the reference which has "NTP" in the Time column and "NTP" in the 1PPS column
to the top of the table, with a Priority value of 1. Click the Enabled checkbox.
For all other references, uncheck the Enabled checkbox, so that they are all disabled.
Configure the NTP Service as described under "Configuring "NTP Stratum Syn-
chronization"" on page 1.
Note: When selecting NTP as an input reference, do not select another reference
(such as GNSS, IRIG, etc.) to work with NTP as a reference. NTP should always
be selected as both the Time and 1PPS input when it is desired to use NTP as an
input reference.
default
references, no additional references need to be
default
references, no additional references need to be
3.3 Managing References
111
