This section is designed to take your through the initial setup steps in order to allow you to com-
municate with and configure your VelaSync.
Figure 2-4:
2.5.1 Connecting the GPS Antenna
For instructions on how to install a
as surge protectors
with the respective equipment.
For additional information regarding the
GNSS Antenna Location" on page 218.
1.
2.5.2 Connecting Power
Before connecting power to the unit, make sure that you have read all safety information
detailed in section "YOUR SAFETY" on page 17.
CHAPTER •
2 VelaSync User's Manual Rev. 1
VelaSync rear panel
, weatherproofing kits
Connect the GPS/GNSS antenna to the GNSS RF connector (see illustration above, item
number 7), using the supplied Type-N adapter cable, and an LMR-400 equivalent cable
with surge suppressor and active GPS L1 antenna, such as Spectracom model 8230.
Note the GNSS receiver connection provides 5V
DANGER! When installing the product, use only the provided or designated
power cables. Using any other cables and adaptors could cause a malfunction or
a fire.
DANGER! This product relies on the building's installation for short-circuit (over-
current) protection. Ensure that the protective device is rated not greater than:
250 V, 20 A.
GPS/GNSS antenna , the signal cable
, or amplifiers , refer to the Installation Guide that came
GPS antenna location
power for the antenna.
DC
2.5 Basic Connections Setup
, and accessories such
selection, see "Choosing a
