1.
The data displayed is linked to a specific Ethernet port e.g., ETH0. If you enable additional Eth-
ernet ports, their throughput data will also be displayed.
In the Traffic pane on the right the traffic throughput in Bytes per second is displayed in two
graphs. Drag the handles at the bottom of the graphs to zoom in on a particular time frame.
In the Actions panel on the left, you can clear or download monitoring data.
In the Status panel on the left, information pertaining to the given Ethernet port is displayed,
including throughput statistics and error statistics. The Mode field indicates which transmission
mode is being used for the given Ethernet port:
Note that the Mode is auto- negotiated by VelaSync. It can be changed only via the switch
VelaSync is connected to, not by using the VelaSync Web UI.
4.7.1.3 NTP Status Monitoring
VelaSync's NTP Status Summary provides a means to monitor NTP status and performance para-
meters relevant to your VelaSync at a glance.
CHAPTER •
4 VelaSync User's Manual Rev. 1
Navigate to TOOLS > SYSTEM: Ethernet Monitor . The Ethernet monitoring screen opens:
FULL duplex, or
HALF duplex.
4.7 Quality Management
177
