In order to apply a static IP address to any Ethernet port, DHCP must be disabled.
To update network settings using a serial connection, please see "Setting Up an IP Address via
the Serial Port" below.
2.7.2 Setting Up an IP Address via the Serial Port
VelaSync's rear panel serial port connector is a standard DB9 male connector. Communication
with the serial port can be performed using a PC with a terminal emulator program (such as
PuTTY or TeraTerm), using a pinned null- modem standard DB9F to DB9M serial cable. The
VelaSync serial port operates at 9600 baud, 8 data bits, no parity, 1 stop bit.
The serial port can be used to make configuration changes (such as the network settings),
retrieve operational data (e.g., GNSS receiver information) and log files, or to perform oper-
ations such as resetting the admin password.
The serial port is account and password protected. You can log in via the serial port using the
same user names and passwords as would be used to log in to the VelaSync Web UI. Users
with administrative permissions can perform all available commands. Users with user per-
missions only can perform "get" commands that retrieve data, but cannot perform any "set"
commands or change/reset any passwords.
To configure an IP address via the serial port:
1.
2.
3.
4.
CHAPTER •
2 VelaSync User's Manual Rev. 1
disable DHCP (selecting this function will provide access to the remaining settings)
assign a static IP address
set netmask values
set Gateway, domain, DNS, and MTU values.
Note: Wait to click
ues to avoid errors.
Connect a serial cable to a PC running PuTTY, Tera Term, or HyperTerminal, and to
your VelaSync. For detailed information on the serial port connection, see "Setting up a
Terminal Emulator" on page 199
Login to VelaSync with a user account that has "admin" group rights, such as the default
account (the default password is
spadmin
Disable DHCP, type:
dhcp4set 0 off
Note: For a list of CLI commands, type
on page 200.
Configure the IP address and subnet mask, type:
ip4set 0 x.x.x.x y.y.y.y
(where is the desired interface, "
0
2.7 Configuring IP Address(es)
Submit or Apply until fully finished assigning val-
).
admin123
<Enter>.
, or see
helpcli
<Enter>
" is the desired IP address for
x.x.x.x
"CLI Commands"
