3.1 Appearance

Front Panel
No.
①
②
③
④
⑤
⑥
Instruction on knob operations:

www.novastar.tech
Name
Indicator R5
LED screen
Knob
BACK
POWER
port
USB
On the home screen, pressing the knob enters the main menu.
3

Hardware Structure

Description
Blue always on: Normal
Red on: Alarm
Orange on: No signal
Blue breathing: Standby
Displays the menu.
Pressing the knob enters a menu or confirms an
option or operation, while rotating the knob selects a
menu item or adjusts a parameter.
Returns to the parent menu.
Pressing it powers on the device, while holding it
down for 4–5 seconds powers off the device.
Connects to the USB drive for firmware upgrade.
3 Hardware Structure
