MCTRL4K Independent Controller
User Manual

3.1 Appearance

Front Panel
No.
①
②
③
④
⑤
Instruction on knob operations:



www.novastar.tech
Name
Power button
USB
LCD screen
Knob
BACK
On the home screen, pressing the knob enters the main menu.
On the main menu, rotating the knob selects a menu item or adjusts the
parameter, and pressing the knob confirms the selection or enters the submenu.
Holding down the knob and BACK button simultaneously for 5 seconds locks or
unlocks all the buttons.
3

Hardware Structure

Description
Pressing it powers on the device, while holding it down for
4–5 seconds powers off the device.
Connects a USB drive only (PC cannot be connected).
Displays the menu.
Pressing the knob enters a menu or confirms an option or
operation. Rotating the knob selects a menu item or
adjusts a parameter.
Returns to the parent menu.
