Aaeon Gene-5310 Manual

All-in-one subcompact board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Gene-5310
All-in-One SubCompact Board
Intel MMX CPU with LCD,
2 Ethernet, Audio, TV-Out, LVDS
& 2 COM Ports

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gene-5310 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aaeon Gene-5310

Summary of Contents for Aaeon Gene-5310

  • Page 1 Gene-5310 All-in-One SubCompact Board Intel MMX CPU with LCD, 2 Ethernet, Audio, TV-Out, LVDS & 2 COM Ports...
  • Page 2 FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPER- ATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A"...
  • Page 3 SiS is a trademark of Silicon Integrated Systems Corp. VIA is a trademark of VIA Technology, Inc. All other product names or trademarks are properties of their respective owners. Part No. 2087531001 Manual Gene-5310 2nd Edition Prepared in Taiwan Sep. 2002...
  • Page 4 Our dealers are well trained and ready to give you the support you need to get the most from your AAEON products. In fact, most problems reported are minor and are able to be easily solved over the phone.
  • Page 5 Because of AAEON’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an AAEON product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time, and freight.
  • Page 6 Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 GENE-5310 All-in-One Single Board Computer • 1 Hard disk drive (IDE) interface cable (44 pin, pitch 2.0mm) • 1 Floppy disk drive interface (34 pin, ptich 2.0mm) •...
  • Page 7 Dear Customer, Thank you for purchasing the GENE-5310 board. This user’s manual is designed to help you to get the most out of the GENE-5310, please read it thoroughly before you install and use the board. The product that you have purchased comes with a two-year limited warranty, but AAEON will not be responsible for misuse of the product.

  • Page 8: Table Of Contents

    Contents Chapter 1: General Informtion......1 Introduction ..............2 LVDS introduction............3 Features .................. 4 Specifications ................. 5 Board layout ................8 Board dimensions ..............10 Chapter 2: Installation ............12 Jumpers and connectors ............ 13 Mechanical Drawing............15 Jumpers...............17 Connectors..............18 RS-232/422/485 COM 2 Setting (J1, JP2)....19 Shift Clock Selection &...
  • Page 9 Chapter 3: Award BIOS Setup ........37 Starting setup ............... 38 Setup keys ................39 Getting help ................. 40 In case of problem ..............40 Main setup menu ..............41 Standard CMOS setup ............43 Advanced BIOS features setup ........48 Advanced Chipset features ..........

  • Page 10: Chapter 1: General Informtion

    General Information This chapter gives background information on the mainboard. Sections include: • Board specifications • Layout and dimensions Chapter 1 General Information...

  • Page 11: Introduction

    SMI. Highly integrated multi-media SBC The GENE-5310 is a highly integrated multi-media SBC that com- bines audio, video, and network functions on a FDD drive size single computer board. It provides an AC-97 audio interface 2.0 version and up to 1024 x 768 resolution @ 16M colors with UMA 8MB SDRAM display memory.

  • Page 12: Lvds Introduction

    LVDS Introduction Low Voltage Differential Signaling is a low noise, low power, low amplitude method for high-speed (gigabits per second) data transmission over copper wire. LVDS differs from normal input/output (I/O) in a few ways: Normal digital I/O works with 5 volts as a high (binary 1) and 0 volts as a low (binary 0). When you use a differential, you add a third option (-5 volts), which provides an extra level with which to encode and results in a higher maximum data tranferrate.

  • Page 13: Features

    • Supports Dual 10/100Base-T Fast Ethernet • Supports Ultra DMA/33 mode with data transfer rate up to 33 MB/sec. • 2 COMs / 1 Parallel / 2 USB / 1 IrDA Port • 5 Volt only operation Gene-5310 User Manual...

  • Page 14: Specifications

    Specifications Standard SBC Functions CPU : Intel Tillamook MMX BGA integrated processor (low power) BIOS: Award 256KB FLASH BIOS Chipset: CBI7 / VT82C686B Memory : Onboard one 144-pin SODIMM socket supports up to 256 Mbytes SDRAM Enhanced IDE: Supports two IDE devices. BIOS auto detect. Supports PIO mode 4 and Bus Master.
  • Page 15 Interface: Onboard pin header supports NTSC/PAL composite output Audio Interface Chipset: VT82C686B Interface: Integrated SoundBlaster, Sound Blaster Pro, and Windows Sound system Ethernet Interface Chipset: Dual Intel 82559GD MicroBGA package Ethernet interface: Onboard Dual 100Base-T RJ-45 connector. SSD Interface Gene-5310 User Manual...
  • Page 16 One socket supports Compact Flash Disk (Type II) Expansion Interface PC/104 connector: One 16-bit 104-pin connector onboard Connectors Mechanical and Environmental Power supply voltage: +5V (4.75V to 5.25V) Operating temperature: 32 to 140 F (0 to 60 Board size: 5.75" (L) x 4" (W) (146 mm x 101.6 mm) Weight: 0.88 lb.

  • Page 17: Board Layout

    Board layout CN19 82559 Gene-5310 User Manual...
  • Page 18 Board layout (Reverse Side) Chapter 1 General Information...

  • Page 19: Board Dimensions

    Board dimensions Gene-5310 User Manual...
  • Page 20 Board dimensions (Reverse Side) Chapter 1 General Information...

  • Page 21: Chapter 2: Installation

    This chapter describes how to set up the main board hardware, including instruc- tions on setting jumpers and connecting peripherals, switches, and indicators. Be sure to read all the safety precautions before you begin the installation procedure. BC-599/596 Gene-5310 User Manual...

  • Page 22: Jumpers And Connectors

    Locating jumpers & connectors CN19 82559 Chapter 2 Installation...
  • Page 23 Locating jumpers & connectors (Reverse side) BC-599/596 Gene-5310 User Manual...

  • Page 24: Mechanical Drawing

    Mechanical Drawing Chapter 2 Installation...
  • Page 25 Mechanical Drawing (Reverse) BC-599/596 Gene-5310 User Manual...

  • Page 26: Jumpers

    Jumpers and connectors Connectors on the board link it to external devices such as hard disk drives, a keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to configure your system to suit your application. The following tables list the function of each of the board's jumpers and connectors.

  • Page 27: Connectors

    LCD Connector for DSTN & TTL Panels CN11 PS/2 Mouse and Keyboard Connector CN12 RJ-45 Ethernet Connector CN13 RJ-45 Ethernet Connector CN14 Audio Connector CN17 USB Connector CN18 FDD Connector CN19 IrDA Connector DIMM1 SO-DIMM Socket Front Panel TV Out Connector BC-599/596 Gene-5310 User Manual...

  • Page 28: Rs-232/422/485 Com 2 Setting (J1, Jp2)

    RS-232/422/485 COM2(J1,JP2) Setting RS-232 RS-422 RS-485 Chapter 2 Installation...

  • Page 29: Shift Clock Selection & Lcd Panel Voltage Setting (J3).20

    SHFCLK 1 2 +5V CLOCK 3 4 LCD Voltage selection SHFCLK 5 6 +3.3V GND 7 8 +3.3V +3.3V SHFCLK 1 2 +5V CLOCK 3 4 LCD Voltage selection SHFCLK 5 6 +3.3V GND 7 8 +3.3V BC-599/596 Gene-5310 User Manual...

  • Page 30: Clear Cmos (J5)

    Clear CMOS (J5) Pin 1~3 You can use J5 pin 1~3 to clear the CMOS data if necessary. To reset the CMOS data, set J5 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed. Clear CMOS (J5) Pin 1~3 Protect* Clear CMOS...

  • Page 31: Power Connector (Cn1)

    Power connector (CN1) In single board computer (non-passive backplane) applications, you will need to connect the power to the Gene-5310 board using CN1. This connector is fully compatible with the standard PC power supply connector. See the following table for its pin...

  • Page 32: Ide Hard Drive (Cn4)

    IDE hard drive connector (CN4) You can attach one or two Enhanced Integrated Device Electronics hard disk drives to the Gene-5310 internal controller. The Gene- 5310 IDE controller uses a PCI local-bus interface. This advanced interface supports faster data transfer and allows the IDE hard drive to exceed 528 MB.
  • Page 33 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND DREQ IO WRITE IO READ IO CHANNEL READY 28 DACK# IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE BC-599/596 Gene-5310 User Manual...

  • Page 34: Serial Port Com2 (Cn6)

    Serial port / COM 2 (CN6) The Gene-5310 offers two serial ports, one RS-232 and one RS-232/ 422/485. These ports allow you to connect them to serial devices (mouse, printers, etc.). COM2 (CN6) Signal Signal CM2-1 CM2-2 CM2-3 CM2-4 SDSRB2X...

  • Page 35: Parallel Port (Cn8)

    DB-25 connector. The cable has a 26-pin connector on one end and a DB-25 connector on the other. Parallel port IRQ The Gene-5310 supports one parallel port. The port is designated as LPT1 and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup.

  • Page 36: Vga Display Connectors (Cn9, Cn10)

    Display connectors (CN9, CN10) The Gene-5310 can drive conventional CRT displays and is capable of driving a wide range of flat panel displays. The board has two connectors to support these displays, one for standard CRT VGA monitors and one for flat panel displays.

  • Page 37: Lcd Connector For Ttl (Cn10)

    You do not have to set any jumpers. LCD connector for TTL (CN10) Signal Signal +12 V +12 V +5 V (or 3.3V) +5 V (or 3.3V) ENAVEE SHF CLK FLM (V SYS) LP (H SYS) ENABKL BC-599/596 Gene-5310 User Manual...

  • Page 38: Lcd Connector For Dstn (Cn10)

    LCD Connector For DSTN (CN10) CN10 is a 44-pin, dual-in-line header used for flat panel displays. When the mainboard's power is applied, the control signal is low until just after the relevant flat panel signals are present. Configuration of the VGA interface is done completely via the software utility.

  • Page 39: Kb & Ps/2 Mouse (Cn11)

    Keyboard and PS/2 mouse connector (CN11) The Gene-5310 provides a keyboard connector which supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. The standard PC/AT BIOS will report an error or fail during power-on-self-test (POST) after a reset if the keyboard is not present.

  • Page 40: Ethernet Connector (Cn 12, Cn13)

    100Base-T Ethernet connector (CN12, CN13) This 100Base-T Ethernet connector is a standard RJ-45 connector. The onboard Intel 82559GD Fast Ethernet controller supports 10Mb/s and 100 Mb/s N-way auto-negotiation operation. Ethernet is the most popular type of local area network, which sends its communications through radio frequency signals carried by a coaxial cable.

  • Page 41: Audio Connector (Cn14)

    Audio connector (CN14) The Gene-5310 provides all major audio signals on a 14-pin flat- cable connector, CN14. Attach the Mic In, Line In, and Audio Out to the corresponding pins as shown in the following table. Audio connector (CN14) Signal...

  • Page 42: Floppy Drive Connector (Cn18)

    Floppy drive connector (CN18) You can attach up to two floppy drives to the mainboard controller. You can use any combination of 5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives. A 34-pin daisy-chain drive connector cable is required for a dual- drive system.
  • Page 43 Floppy drive connector (CN18) Floppy drive connector (CN18) Signal Signal DENSITY SELECT INDEX MOTOR 0 DRIVE SELECT 1 DRIVE SELECT 2 MOTOR 1 DIRECTION STEP WRITE DATA WRITE GATE TRACK 0 WRITE PROTECT READ DATA HEAD SELECT DISK CHANGE BC-599/596 Gene-5310 User Manual...

  • Page 44: Irda Connector (Cn19)

    IrDA connector (CN19) The IrDA connector (CN19) can be configured to support wireless infrared module, with this module and application software such as laplink or Win95/98 Direct Cable connection, user can transfer files to or from laptops, notebooks, PDA and printers. This connector supports HPSIR (115.2Kbps, 2 meters), ASK-IR (56Kbps) and Fast IR (4Mbps, 2 meters).

  • Page 45: Front Panel (J2)

    GND / Power LED GND / IDE LED EXTSMI / GND RESET / GND TV-output connector (J4) The Gene-5310 has an eight pin connector offering tv output connection. The pin definition is listed below. TV-Out 4*2 Pin Connector (2.0mm) (J4) Signal Signal...

  • Page 46: Chapter 3: Award Bios Setup

    Award BIOS Setup This chapter describes how to configure the BIOS for the system. Chapter 3 Award BIOS Setup...

  • Page 47: Starting Setup

    Ctr-Alt-Del. If you do not press the keys at the correct time and the system does not boot, an error message appears and you are again asked to PRESS F1 TO CONTINUE, DEL TO ENTER SETUP GENE-5310 User Manual...

  • Page 48: Setup Keys

    S etup k eys These keys helps you navigate in Award BIOS: Up arrow Mo ve to pre vi ous item Do wn arrow Move to n ext item Le ft arrow Mo ve to the item in th e l eft hand Ri ght arrow Move to the item in the ri ght hand Es c...

  • Page 49: Getting Help

    The Chipset defaults have been carefully chosen by Award Software or your system manufacturer for the best performance and reliability. Even a seemingly small change to the Chipset setup may cause the system to become unstable. GENE-5310 User Manual...

  • Page 50: Main Setup Menu

    Main Setup Menu Standard CMOS Features Use this menu for basic system configuration. (Date, time, IDE, etc.) Advanced BIOS Features Use this menu to set the advanced features available on your system. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system’s performance.
  • Page 51 Set Supervisor/User Password Use this menu to set User and Supervisor Passwords. Save and Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup. GENE-5310 User Manual...

  • Page 52: Standard Cmos Setup

    Standard CMOS Features This standard setup menu allows users to configure system components such as the date, time, hard disk drive, floppy drive, display, and memo ry. Online help for each field can be accessed by pressing F1. Date and Time Configuration The BIOS determines the day of the week from the other date information.
  • Page 53 (Logical Block Addressing): During drive access, the IDE controller transforms the data ad dress described by sector, head, and cylinder number into a physical block address, significantly improving data transfer rates. For drives with greater than 1024 cylinders. GENE-5310 User Manual...
  • Page 54 Here is a brief explanation of drive specifications: Type: The BIOS contains a table of predefined drive types. Each defined drive type has a specified number of cylinders, number of heads, write precompensation factor, landing zone, and number of sectors. Drives whose specifications do not accommodate any predefined type are classified as type USER.
  • Page 55 American National Television Systems Committee(NTSC) color television system and the French Sequential Couleur avec Memoire (SECAM). NTSC is also used in Japan. SECAM is used in countries of the former Soviet Union. The choices: NTSC, PAL, Disable GENE-5310 User Manual...
  • Page 56 LCD&CRT GENE-5310 can be used with various visual display peripherals. It can also display the same image on both a CRT and LCD monitor simultaneously. This function allows the end user to select the type of visual display peripheral they are incorporating with the GENE-5310 single board computer.

  • Page 57: Advanced Bios Features Setup

    NOTE: Many disk diagnostic programs that access the boot sector table can trigger the virus warning message. If you plan to run such a program, we recommend that you first disable the virus warning. GENE-5310 User Manual...
  • Page 58 CPU Internal Cache/External Cache Cache memory is additional memory that is much faster than conventional DRAM (system memory). CPUs from 486-type on up contain internal cache memory, and most, but not all, modern PCs have additional (external) cach e memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU.
  • Page 59 MB (extended memory). When set to Fast, the system chipset controls Gate A20. When set to Normal, a pin in the keyboard controller controls Gate A20. Setting Gate A20 to Fast improves system speed, particularly with OS/2 and Windows. GENE-5310 User Manual...
  • Page 60 Typematic Rate Setting Key strokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected. The choice: Enabled/Disabled Typematic Delay When the typematic rate setting is enabled, you can select a typematic delay (the delay before key strokes begin to repeat) of 250, 500, 750 or 1000 milliseconds.
  • Page 61 ROM occupies to shadow it into the correct area of RAM. Small Logo (EPA) Show The choices: Enabled, disabled Cyrix 6x86/MII CPUID Disable CPUID instructions if you are using Netware version 5.0. GENE-5310 User Manual...

  • Page 62: Advanced Chipset Features

    Advanced Chipset Features Bank 0/1 Dram Timing The value in this field depends on performance parameters of the installed memory chips (DRAM). Do not change the value from the factory setting unless you are qualified. Bank 2/3 Dram Timing The value in this field depends on performance parameters of the installed memory chips (DRAM).
  • Page 63 PBSRAM access at 66 or 75 MHz Cache P/CPU W Pipeline The choices: Enable, disable. Cache Timing For a secondary cache of one bank, select faster. For a secondary cache of two banks, select fastest. The choices: Fast, Fastest GENE-5310 User Manual...
  • Page 64 Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory. The choices: 15-16 M, disabled Initial Display first This function allows the end user to determine their primary display.
  • Page 65 USB Keyboard Support Select enabled if your system contains a Universal Serial Bus controller and you have a USB keyboard. OnChip Sound This item allows you to control the onboard VIA 1611 audio. The choices: Auto, disabled GENE-5310 User Manual...
  • Page 66 CPU to PCI Write Buffer When this field is enabled, writes from the CPU to the PCI bus are buffered, to compensate for the speed differences between the CPU and PCI bus. When, disabled, the writes are not buffered and the CPU must wait until the write is complete before starting another write cycle.
  • Page 67 Memory Parity / ECC Check Select enabled, disabled or Auto. In auto mode the BIOS enables memory checking automatically when it detects the presence of ECC or parity DRAM. GENE-5310 User Manual...

  • Page 68: Integrated Peripherals

    Integrated Peripherals On-Chip IDE Channel 0 The system chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the primary and/or secondary IDE interface. Select Disabled to deactivate this interface, if you install a primary and/or secondary add-in IDE interface.
  • Page 69 (Windows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your IDE Cable both support Ultra DMA 33/66 select Auto to enable BIOS support. The choices: Auto, disable IDE HDD Block Mode Select Enabled only if your hard drives support block mode. GENE-5310 User Manual...
  • Page 70 Onboard FDC/FDD Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install an add-in FDC or the system has no floppy drive, select Disabled in this field.
  • Page 71 The Choice: 378/IRQ7, 278/IRQ5, 3BC/IRQ7, disabled Parallel Port EPP Type Select EPP port type 1.7 or 1.9. Parallel Port Mode Two bidirectional parallel ports. Supports Normal, ECP, EPP, ECP + EPP. ECP Mode Use DMA Select a DMA channel for the port. GENE-5310 User Manual...
  • Page 72 Onboard Legacy Audio Onboard Legacy Audio can be set as enabled or disabled. However disabling the Legacy Audio will render the functions listed below useless. Sound Blaster The on board Sound Blaster can be configured as enable or disable. SB I/O Base Address Select a base I/O address for the Sound Blaster interface.

  • Page 73: Power Management Setup

    1. HDD Power Down 2. Doze Mode 3. Suspend Mode Maximum Saving 1. HDD - 1~15 minutes or Disable 2. Doze Mode - 1 Minute 3. Suspend Mode - 1 Minute GENE-5310 User Manual...
  • Page 74 Minimum Saving 1. HDD - 1~15 minutes or Disable 2. Doze Mode - 1 Hour 3. Suspend Mode - 1 Hour User Define 1. HDD - 1~15 minutes or Disable 2. Doze Mode - 1 min, 2 min, 4 min, 6 min, 8 min, 10 min, 20 min, 30 min, 40 min, 1 hour.
  • Page 75 When enabled, you can set the VGA to awaken the system LPT & COM When LPT & COM is set to ON, any activity from one of the system peripheral devices or IRQs, wakes up the system. GENE-5310 User Manual...
  • Page 76 HDD & FDD When HDD & FDD is set as ON, any activity from one of the listed system peripheral devices wakes up the system. PCI Master When PCI Master is set as ON, any activity from one of the listed system peripheral devices wakes up the system.

  • Page 77: Pnp/Pci Configurations

    Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. The choices: Enabled, Disabled GENE-5310 User Manual...
  • Page 78 Resources Controlled By The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows ® 95. If you set this field to “manual”...

  • Page 79: Pc Health Status

    PC Health Status PC Health Status Your system does not allow you to alter any of the setting in this menu. The system engineer has already designated the correct setting for Gene-5310. GENE-5310 User Manual...

  • Page 80: Frequency Voltage Control

    Fre quency/Volta ge C ontrol Auto Detect DIMM/PCI CLK This item allows you to enable/disable auto detect DIMM/PCI clock. The choices: Enable/Disable Spread Spectrum This allows you to enable/disable the spread spectrum modulate. When the system clock generator pulses, the extreme values of the pulse generate excess EMI.

  • Page 81: Load Fail-Safe Defaults

    When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Default (Y/N)? Pressing “Y” loads the BIOS default values for the most stable, minimal performance system operations. GENE-5310 User Manual...

  • Page 82: Load Optimized Defaults

    Load Optimized Default Load Optimized Default When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N)? Pressing “Y” loads the default values that are factory settings for optimal performance system operations Chapter 3 Award BIOS Setup...

  • Page 83: Set Supervisor Password

    System Enter a password each time the system boots and when ever you enter Setup. Setup Enter a password when ever you enter Setup. NOTE: To clear the password, simply press Enter when asked to enter a password. Then the password function is disabled. GENE-5310 User Manual...
  • Page 84 Se t User Pas swo rd When you select this function, a message appears at the center of the screen: ENTER PASSWORD: Type the password, up to eight ch aracters, and press Enter. Typing a password clears any previously entered password from CMOS memory.

  • Page 85: Save To Cmos And Exit

    The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS. After saving the values the system is restarted again. GENE-5310 User Manual...

  • Page 86: Exit Without Saving

    Exit without Saving Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit Without Saving (Y/N)? This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer.
  • Page 87 DRIVERS INSTALLA- TION This Gene-5310 is equipped with an audio, VGA and LAN interface. This chapter provides instructions for installing the software drivers on these peripherals. Gene-5310 User Manual...

  • Page 88: Chapter 4 Driver Installation 79

    VGA Driver Installation for Windows OS =>Insert the Gene-5310 CD Diskette into the CD ROM Drive. =>Click on the Start Button =>Click on the Settings ICON =>Click on the Control Panel ICON =>Click on the Systems ICON =>Click on the Device Manager Tab =>Click on the Display Adapter File...

  • Page 89: Ethernet 82559Gd Driver

    Intel 82559GD Driver Installation for WIN. OS *The ethernet driver installation procedure must be performed twice, because Gene-5310 has two Ethernet ports onboard* =>Insert the Gene-5310 CD Diskette into the CD ROM Drive. =>Click on the Start Button =>Click on the Settings ICON =>Click on the Control Panel ICON...

  • Page 90: Audio Driver

    Audio Driver Installation for Windows OS =>Insert the Gene-5310 CD Diskette into the CD ROM Drive. =>Click on the Start Button =>Click on the Settings ICON =>Click on the Control Panel ICON =>Click on the Systems ICON =>Click on the Device Manager Tab =>Select the Sound Controller File...
  • Page 91 Gene-5310 User Manual...
  • Page 92 Programming the Watch- dog Timer The mainboard is equipped with a watch- dog timer that resets the CPU or generates an interrupt if processing comes to a stand- still for whatever reason. This feature en- sures system reliability in industrial stand- alone and unmanned environments.

  • Page 93: Appendix A: Programming The Watchdog Timer

    -- access the I/O port 0x443, e.g. outportb(0x443, data); // refresh watchdog timer * note: if you want to refresh the watchdog timer, you have to disable it first. Gene-5310 User Manual...

  • Page 94: Demo Program

    D e m o p r o g r a m outportb(0x444, 0): // set time-out event to reset-system outportb(0x443x 10 ); // set time-out interval to 10 seconds customer_job(); // execute your job here, be sure your job will finished within 10 seconds outportb(0x443, 0);...
  • Page 95 Gene-5310 User Manual...
