The Interaction Edge installation and configuration is complete and you are ready to begin the initial
configuration of the Interaction Gateway software.

Assign the Interaction Edge IPv4 address through the LCD panel

This procedure sets the IP address for the NIC1 interface of Interaction Edge. If you have split the teamed
network interfaces, you must use the Interaction Edge web UI to set the IP address of NIC2. For more
information about setting the IP address of NIC2 in a split network interface configuration, see
Interaction Edge IPv4 address through the web
Note:
If you do not have a DHCP server, you must manually assign an available static IPv4 address through
the LCD panel.
1. Press and release the lower right button to enter the Configuration menu.
The LCD Panel displays Status About.
2. Press the lower right button to display Settings System in the LCD panel.
3. Press the upper left button to enter the Settings System configuration menu.
The Machine Name menu item is displayed.
4. Press the lower right button until the Address Type menu item is displayed.
5. Press the upper left button to edit the Address Type menu item.
6. Press the lower right button until Static IP is displayed.
7. Press the upper left button to confirm Static IP as the Address Type.
8. Press the lower right button once to display the Host IP Address menu item.
9. Press the upper left button to edit the IPv4 address.
10. Move the cursor along the IPv4 address by using the upper left and upper right buttons. Once you reach
a digit that you want to change, proceed to the next step.
11. Use the lower left and lower right buttons to change the digit.
Note:
When you are changing digits, you can only move between 0 (zero) and 9. The sequence of
digits does not restart to the beginning or the end of the list. For example, if the current digit
is 9 and you attempt to go to the next higher number, 0 (zero) is not displayed; only 9, as it is
the end of the digit sequence.
12. When you have finished configuring the IPv4 address, move the cursor to the right—using the upper right
LCD panel button—until a check mark is displayed in the LCD panel button icons.
13. Press the upper left button, which corresponds to the check mark icon in the LCD panel, to confirm the
change. If you want to cancel your changes, press the lower left button, which corresponds to the X icon
in the LCD panel.
14. Press the lower left button to return to the Settings System menu.
15. Press the lower right button to scroll to the Apply menu item.
16. Press the upper left button, which corresponds to the check mark icon in the LCD panel, to confirm.
Interaction Edge restarts and the static IP address is assigned to NIC1.
interface.
