ZXMSG 5200 (V2.0) Technical Manual

Rack Parameters

The ZXMSG 5200 can be installed in an indoor or outdoor type rack. The
indoor model is ZXA10-ONUB-IN/1500. The outdoor model is ZXONU-
OUT30 or ZXONU-OUT40.
The working parameters for the ZXA10-ONUB-IN/1500 are as follows:
DC voltage: -57 V DC ~ -40 V DC
AC power supply: 200 V AC ~ 240 V AC
Power consumption (full load): About 700 W
Working humidity: 20% ~ 80%
Working temperature: 0ºC ~ +40ºC
Waterproof
International Electrotechnical Commission (IEC).
Internal battery: Four pieces of 12 V 100 Ah batteries
Rack weight: About 210 kg (without batteries)
The working parameters for the ZXONU-OUT30 are as follows:
AC power supply: 200 V AC ~ 240 V AC
DC voltage: -56 V DC ~ -40 V DC
Power consumption: 350 W (maximum equipment power in the
cabinet) + 1500 W (power of air conditioners).
Working temperature: -35ºC ~ +55ºC
Relative humidity: 5% ~ 90%
Temperature control solution: To use industrial air conditioner
Waterproof
International Electrotechnical Commission (IEC).
Internal battery: Four pieces of 12V 100 Ah batteries
Rack weight: About 320kg (without batteries and air conditioner)
The working parameters for the ZXONU-OUT40 are as follows:
AC power supply: 200 V AC ~ 240 V AC
DC voltage: -56 V DC ~ -40 V DC
Power consumption: 430 W (maximum equipment power in the
cabinet) + 1500 W (power of air conditioners).
Working temperature: The normal working temperature should be
within -35ºC ~ +50ºC (with the consideration of sunny radiation).
No more than 4 hours' operation under the maximum temperature
+55ºC.
Relative humidity: 5% ~ 90%
Temperature control solution: To use industrial air conditioner or heat
exchanger
26 Confidential and Proprietary Information of ZTE CORPORATION
and dustproof requirements:
and dustproof requirements:
IP 5.5 level of the
IP 5.5 level of the
