ZXHN H196Q
Home Gateway
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXHN H196Q and is the answer not in the manual?

Questions and answers

Summary of Contents for Zte ZXHN H196Q

  • Page 1 ZXHN H196Q Home Gateway User Manual...
  • Page 3 Additionally, the contents of this document are protected by contractual obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners. This document is provided “as is”, and all express, implied, or statutory...
  • Page 4 ZTE CORPORATION reserves the right to upgrade or make technical change to this product without further notice. Users visit technical support website http://sup- port.zte.com.cn to inquire related information. The ultimate right to interpret this product resides in ZTE CORPO- RATION.
  • Page 5 Safety Precautions Before using the device, read the following safety precautions. ZTE bears no liability to the consequences incurred by violation of the safety instructions. Usage Cautions  Read all the safety cautions carefully before using the device.  Only use the accessories included in the package, such as power supply adapter and battery.
  • Page 6 nance if the device is faulty. Environment Requirements  Ensure proper ventilation to the device. Place the device away from direct sunlight.  Keep the device ventilated and dry. Never spill any liquid on the device.  Do not place any object on the device to prevent any deformation or damage to the device.
  • Page 7 Cleaning Requirements  Before cleaning, power off the device, and unplug all the cables connected to the device, such as power cable, optical fiber, and Ethernet cable.  Do not use any liquid or spray to clean the device. Use a soft dry cloth. Environment Protection ...
  • Page 8  Gigabit Ethernet WAN Uplink The ZXHN H196Q can provide Internet access through Gigabit Ethernet WAN connection. So it is possible for ZXHN H196Q to provide Internet ac- cess choices to suit various broadband access network.  GE LAN Ports...
  • Page 9 Output: DC 12.0 V, 1.5 A Environment Requirements 0 °C – 40 °C (32 °F – 104 °F) Operation temperature 5% – 95% (non-condensing) Operation humidity 2.2 Package Check After unpacking the ZXHN H196Q product, check that the following items are complete.
  • Page 10 If any item is found to be wrong, missing, or damaged, contact your service provider. Keep the package and all the items in good condition if you want to replace the product. Installation Preparation 3.1 Hardware Description Front panel Figure 3-1 shows the front panel of the ZXHN H196Q.
  • Page 11 Figure 3-1 The Front Panel Indicator Status Definition Color The device is being started or the device is Solid abnormal.
  • Page 12 The uplink connection is failured, or failure Flashing to configure synchronization in the Extender mode. Green Solid The uplink connection is normal. The WPS negotiation connection is being Flashing implemented. In the Extender mode, the wireless uplink signal is strong, or the connection is successful Blue Solid and the configuration synchronization is...
  • Page 13 Figure 3-2 The Rear Panel Interface/Button Function Power supply port, it is connected to the power Power adapter.
  • Page 14 During power ON period, hold on this button for more than 5 seconds to reset the current settings to the Reset factory default setting, and then the system restarts automatically. RJ-45 port, it is used to to connect to the uplink access network.
  • Page 15 Function Interface/Button Standard USB interface, connected to a USB storage device for file sharing, fast backup, and data restoration. WPS Push Button, press this button to enable or WPS* disable the WPS function. • *The WPS button is located in the front of the device, but there is no mark. 3.2 Hardware Connection Figure 3-3 shows the devices that are connected to interfaces of the ZXHN H196Q.
  • Page 16 The factors affecting the wireless network coverage range include the location of the product, distance between the product and a wireless terminal, num- ber of obstacles, obstacle material and density, and interference source. is recommended that you place the product in accordance with the following principles to maximize the strength of wireless signals.
  • Page 17  The product should be installed on the same floor as the applied area.  Do not put other objects on the product. Try to reduce the number of obsta- cles between the product and a wireless terminal.  Horizontally place the product in the middle of the applied area and do not put it in a corner.
  • Page 18 and the Ethernet cable is correctly connected to the LAN interface.  Check the indicator on the front panel is solid red or flashing red. Restore the factory default settings. After the power is on, use a needle to press the button for over 5 seconds to restore the default factory settings.
  • Page 19 which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.
  • Page 20 brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. This equipment complies with ISED RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.
  • Page 21 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
