F P
F 1 0
R O N T A N E L O F
I G U R E
ADL
3. LED Indicators
T 7 A D L G I
A B L E N D I C A T O R S
LED Status Description
RUN Slow blinking: The card is working normally
ALARM On: The card is abnormal
On:
ETHERNET
received/transmitted (for the 100 M Ethernet interfaces on the
panel).
ADSL1 ADSL 1 is successfully set up
ADSL2 ADSL 2 is successfully set up
ADSL3 ADSL 3 is successfully set up
ADSL4 ADSL 4 is successfully set up
ADSL5 ADSL 5 is successfully set up
ADSL6 ADSL 6 is successfully set up
ADSL7 ADSL 7 is successfully set up
A D L G
A link is present.
