ZXMSG 5200 (V2.0) Technical Manual
F 5 Z X M S G 5 2 0 0 H
I G U R E
LC0
Control shelf
LC0
Subscriber shelf

Structure Layout Diagram

Figure 6 shows the structure arrangement of the ZXMSG 5200 in a
maximum configuration, where there are five shelves, including one main
control shelf and four subscriber shelves. The board is 6U high.
The system supports maximum 1,856 lines of narrowband subscribers,
where the main control shelf serves 320 lines and the extension shelf
serves 384 lines; supports maximum 928 lines of ADSL subscribers, where
the main control shelf serves 160 lines and the extension shelf serves 192
lines.
32 Confidential and Proprietary Information of ZTE CORPORATION
S
A R D W A R E T R U C T U R E
100M Ethernet
8K,2M,4M Clock
2M Hw
LC1 ... LC9 TSLC
100M Ethernet
8K,2M,4M Clock
2M Hw
LC1 ... LC9
LC10
2*100M, 1GE
CNIC
ICS IC MPR
S
1*8MHw 1*100M
ICS
IC
S
TSLC
LC11
Ethernet
2*100M
MPR
2*8MHw
