19.2 Spare Parts Kits

Table 24: Spare Parts Kits
Ref. Description
Cover:
1 Yellow
2 Black
3 White
Boards:
Main
4
LCD
5
Pressure Sensor
6
Multi-Function Card
7
Safety Discrete Output Card
8
Pilot Relay Module:
9 Single Acting (Poppet)
10 Double or Single Acting (Spool)
Switches:
11 Mechanical Switch
12 Reed Switch
13 P&F SJ2-SN
14 P&F SJ2-S1N
15 P&F NJ2-V3-N
16 P&F NBB2-V3-E2 (2-wire configuration)

19.3 Mounting Kits

Table 25: Mounting Kits
Description
IEC 534 part 6
(FloTop, Kämmer KA, Kämmer KP, and standard
NAMUR linear valves)
Rotary VDI/VDE 3845
(DIN ISO 5211)
Flowserve direct mounting
Linear VDI / VDE 3847
© Flowserve Corporation
User Instructions - Logix® 520MD+ Series Digital Positioner
Part-no.
283450.999.000
283451.999.000
283452.999.000
283453.999.000
283454.999.000
283455.999.000
11 - 16
283456.999.000
283457.999.000
283458.999.000
283459.999.000
TBD
TBD
4
TBD
TBD
TBD
TBD
7, 8
Part-no.
213619.999.000
188151.999.000
214004.999.000
255242.999.000
54
FCD LGENIM0105-00
Figure 33: Spare Parts Kits
Field Trial Version – Printed October 28, 2011
1 - 3
5
6
9, 10
