10.3 Menu Features

10.3.1 Status
►Status
►Command (mA)
►Command (%)
►Position (%)
►PS (Supply Pressure)*
►PA (Port A Pressure)*
►PB (Port B Pressure)*
►Friction**
►Actuation Ratio**
►Pneumatic Leak**
►Temperature
►Valve Cycles
►Valve Travel (%)
►Card 1 Value
►Card 2 Value
* Requires Advanced positioner upgrade.
** Requires Pro positioner upgrade.
The Status menu is used to view information about the
configuration and operation of the system.
Command displays the final command in mA.
Command displays the final command in %.
Position displays the valve position in %.
PS displays the supply pressure.
PA displays the pressure in port A. This is the primary port if
using a poppet-style relay module.
PB displays the pressure in port B. This is the primary port if
using a spool-style relay module.
Friction displays the friction of the actuator/valve assembly.
Actuation Ratio displays the force required to actuate the
valve as a percentage of the total force available. The value
is an estimate of the force that would be required to move the
valve to the end of travel, fully compressing the actuator
spring(s).
Pneumatic Leak is an estimate of leak in addition to regular
air consumption.
Temperature displays the temperature inside the positioner.
Valve Cycles are counted each time the positioner changes
direction. The movement must be beyond a dead-band
window. This window is set to 0.5% as a default, but can be
changed using the DTM.
Valve Travel is counted in small increments every time the
valve moves beyond the dead-band window. The travel is
displayed in % of full stroke.
Card 1 Value shows the configuration and status of the
auxiliary card in slot 1. A tripped state is represented by a 0.
A nominal state is represented by a 1.
Card 2 Value shows the configuration and status of the
auxiliary card in slot 2. A tripped state is represented by a 0.
A nominal state is represented by a 1.
For example, if the Multi-Function Card (MFC) was in slot 1,
configured as an analog output (AO), and giving 12.34 mA,
the display would show "AO 1 12.34mA". If no card is in the
slot, the display will show "No Card".
For more information about auxiliary card status, see Table
12: Auxiliary Card Status.
