3.8 Positioner Performance
Characteristics
Table 8: Performance Characteristics
≤ 0.25%
Resolution
Linearity +/-1.25%
≤ 0.25%
Repeatability
≤ 1.0%
Hysteresis
≤ 0.3%
Deadband
≤ 0.25%
Sensitivity
≤ 0.4%
Stability
≤ 0.5%
Long term drift
≤ 0.2%
Supply Pressure Effect
3.9

Physical Specifications

Table 9: Physical Specifications
Housing Material Cast, powder-painted aluminum
Soft Goods Fluorosilicone
Weight of Base With Single Acting Relay
Positioner Without
Accessories
With Double Acting Relay

3.10 Limit Switch Specifications

Table 10: Limit Switch Specifications
Switch Specifications
Mechanical Load current:
Cherry DG 13-B(X)RA Voltage:
NO and/or NC Temperature:
Reed Load current:
Hamlin 59050-030 Voltage:
NO Temperature:
Inductive Proximity Load current:
P&F SJ2-SN
NAMUR NC Voltage:
Temperature:
Inductive Proximity Load current:
P&F SJ2-S1N
NAMUR NO Voltage:
Temperature:
Inductive Sensor Load current:
P&F NJ2-V3-N
NAMUR NC Voltage:
Temperature:
Inductive Sensor Load current:
P&F NBB2-V3-E2 Voltage:
PNP NO Temperature:
© Flowserve Corporation
User Instructions - Logix® 520MD+ Series Digital Positioner
1,76 kg (3,88 lb)
1,88 kg (4,14 lb)
3/2 AAC/ADC
125/30 VAC/VDC
-25 to +85 ° C
(-13 ° F to 185 ° F)
500 mA
200VDC
-40 to +105 ° C
(-40 ° F to 221 ° F)
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
5-25 VDC
(Nominal 8 VDC)
-40 ° C to 100 ° C
(-40 ° F to 212 ° F)
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
5-25 VDC
(Nominal 8 VDC)
-25 ° C to 100 ° C
(-13 ° F to 212 ° F)
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
Nominal 8.2 VDC
-25 ° C to 100 ° C
(-13 ° F to 212 ° F)
0...100 mA
10...30 VDC
-25 ° C to 70 ° C
(-13 ° F to 158 ° F)
3.11 ValveSight DTM Software
Specifications
Table 11: ValveSight DTM Software Specifications
Computer Minimum Pentium processor running
Windows 95, 98, NT, 2000, XP, 32 MB
total memory (64 MB recommended), 30
MB available hard disk space, CD-ROM
drive
Ports 1 minimum available with 8 maximum
possible. (Can also communicate via
serial, PCMCIA and USB connections)
HART Modem RS-232,
PCMCIA card, or
USB
HART Filter May be required in conjunction with some
DCS hardware.
HART MUX MTL 4840/ELCON 2700
8
Field Trial Version – Printed October 28, 2011
FCD LGENIM0105-00
