Table XI: Parts (continued)
Item No. Part
23 Screw, Anti-rotation
24 Screw, User Interface Board (3)
25 User Interface Board Potted Assembly
26 O-ring, User Interface Board
27 Grounding Screw (2)
28 Threaded Plug
29 Main Vent Cover
30 Screw, Main Vent Cover
31 Driver Module Cover
32 O-ring, Driver Module Cover
33 Driver Module Assembly
34 Hex Barbed Fitting with Captive O-ring
35 Flexible Tubing
36 Screw, Driver to Housing
37 Nylon Washer
38 Spool Valve
39 Spool Valve Block

11 Logix 3400MD Spare Parts Kits

Table XII: Spare Parts Kits
Item
Description
No.
Kit 2: Driver Module Assembly -40° to 80°C Kit, P/N 199786.999.000
16 Pressure Regulator
17 Screw, Regulator to Housing
33 Driver Module Assembly
34 Hex Barbed Fitting w/ Captive O-ring
36 Screw, Driver to Housing
37 Nylon Washer
Kit 3: Spool Assembly Valve Kit, P/N 199787.999.000
38 Spool
39 Spool Valve Block
40 Screw, Spool Valve to Housing
41 O-ring, Spool Valve
Kit 4: Pressure Regulator, P/N 215814.999.000
16 Pressure Regulator with Captive O-rings
17 Screw, Regulator to Housing
Kit 5: Feedback Shaft Kit, P/N 199788.999.000 - ATEX & IECEX ONLY
52 Feedback Shaft
53 Screw, Spring to Feedback Shaft
54 O-ring, Feedback Shaft
Logix 3400MD Digital Positioner FCD LGENIM3404-00 – 9/09
Item No. Part
40 Screw, Spool Valve to Housing (2)
41 O-ring, Spool Valve (3)
42 Screw, Spool Valve Cover
43 Spool Valve Shroud
44 Spool Valve Cover
45 Hydrophobic Filter, Spool Valve Chamber
46 O-ring, Spool Valve Cover
47 Pressure Gauge, 0-160 psig (2)
48 Air Screen (3)
49 Screw, Position Feedback Potentiometer to Housing (2)
50 Metal Washer (2)
51 Position Feedback Potentiometer
52 Feedback Shaft
53 Screw, Spring to Feedback Shaft
54 O-ring, Feedback Shaft
55 Torsion Spring
56 E-ring
(See Figure 22 for item numbers.)
Item
Quantity Description
No.
55 Torsion Spring
1 56 E-ring
4 Kit 6: Feedback Shaft Kit (NAMUR), P/N 218814.999.000 - ATEX & IECEX
ONLY
1
52 Feedback Shaft
1
53 Screw, Spring to Feedback Shaft
1
54 O-ring, Feedback Shaft
1
55 Torsion Spring
56 E-ring
1
Continued on Page 46
1
2
3
1
4
1
1
1
Quantity
1
1
1
1
1
1
1
