- Page 1 User Instructions Logix 505si - LGENIM0505-00 03/09 USER INSTRUCTIONS ® Installation Logix 505si Series Digital Positioner Operation Maintenance FCD LGENIM0505-00 03/09 Experience In Motion...
-
Page 2: Table Of Contents
Trouble Shooting ............11 Protective clothing Spare parts ..............12 Dimensions ..............14 FLOWSERVE products are often used in problem- atic applications (e.g. extremely high pressures, dangerous, toxic or corrosive mediums). In particular valves with bellows seals point to such applications. -
Page 3: Unpacking
FLOWSERVE for repair or service FLOWSERVE must STOP! be provided with a certificate which confirms that the product has been decontaminated and is clean. FLOWSERVE will not accept deliveries if a certificate has not been provided (a form can be obtained from FLOWSERVE). Storage In most cases FLOWSERVE products are manufactured from stainless steel. -
Page 4: Logix 505Si Overview
User Instructions Logix 505si - LGENIM0505-00 03/09 ® LOgix 505si OVERViEW pressure to the actuator’s maximum rating (not to be The Logix 505si is a two-wire, 4-20 mA input digital confused with operating range). A coalescing air filter valve positioner. The Logix 505si positioner controls is recommended for all applications due to the close single-acting actuators with linear and rotary mount- tolerances in the positioner. -
Page 5: Principle Of Operation
User Instructions Logix 505si - LGENIM0505-00 03/09 ® Filter / Regulator for Supply Air 2 Electro-pneumatic Converter Module 1.5 – 6.0 bar (22 – 87 psi) Air Supply 1 Digital Control Circuit Pressure Regulator Inner Loop Piezo Control Inner Loop Position Feedback 4 –... -
Page 6: Connection Description
User Instructions Logix 505si - LGENIM0505-00 03/09 ® Table 10: Connection Table Connection Description Input+ 4..20 mA Input- 4..20 mA Y (0⇒) Pneumatic output signal (outlet) Z (0⇐) Air supply 4-20 mA Signal Internal Housing EARTH Terminal Connect Shield at Source Ground Shielded Cable 4-20 mA Current Source Figure 2: Wiring Diagram... -
Page 7: Startup
An electromagnetic line filter can be used to further eliminate noise (FLOWSERVE Part Number 10156843). -
Page 8: Setup Of The Cal Dipswitches
User Instructions Logix 505si - LGENIM0505-00 03/09 ® Configuration Switches LED Status Lights Quick-Cal Switch 4-20 mA Input Figure 4: Logix 505si Local interface Split range - Split range selection is used to limit the It also optimizes the response for valves and actuators action control region to either 4 - 12 mA or 12 - 20 mA. -
Page 9: Error Codes
User Instructions Logix 505si - LGENIM0505-00 03/09 ® 9 STATUS CODES Logix 505si Status Condition Codes Colors identifier indication and resolution g - - - Any sequence starting with a Green light flashing first is a normal operating mode and indicates that there are no internal problems. - Page 10 User Instructions Logix 505si - LGENIM0505-00 03/09 ® Logix 505si Status Condition Codes Colors identifier indication and resolution YGRY Analog output span too small - The span must be calibrated to a range greater than 3.0 mA. This error may be cleared by briefly pushing the quick-cal button, which will force the positioner to use the parameters from the last good calibration.
-
Page 11: Trouble Shooting
User Instructions Logix 505si - LGENIM0505-00 03/09 ® 10 TROUbLESHOOTing LOgix 505Si DigiTAL POSiTiOnERS Failure Probable Cause Corrective action No LED is blinking 1. Current source below 3.6 mA 1. Verify current source is outputting at least 3,6 mA 2. Incorrect wiring polarity 2. -
Page 12: Spare Parts
Mounting Kits Description Part-no. – IEC 534 part 6 (FloTop, Kämmer KA, Kämmer KP, and standard NAMUR linear valves) 213619.999.000 – Rotary VDI/VDE 3845 (DIN ISO 5211) 188151.999.000 – Flowserve direct mounting 214004.999.000 – Linear VDI / VDE 3847 255242.999.000... - Page 13 User Instructions Logix 505si - LGENIM0505-00 03/09 ® Fig 5: Exploded drawing for spare parts...
-
Page 14: Dimensions
User Instructions Logix 505si - LGENIM0505-00 03/09 ® Dimensions EXTERIOR GROUNDING LED WINDOW SCREW M20X1,5 OR G1/4" OR FRONT VIEW 1/4" NPT 1/2" NPT 22.95 32.00 98.14 10.00 4.00 4.80 "D" SHAFT OPTION (STANDARD) 4.00 10.00 2.31 174.10 "N" SHAFT OPTION 6.85 64.10 (VDI/VDE 3845, NAMUR) - Page 15 User Instructions Logix 505si - LGENIM0505-00 03/09 FIG. 6 - DIMENSIONAL DRAWING FOR OPTIONS ® SINGLE PRESSURE GAUGE 1/4" NPT 100.00 3.94 216.18 8.51 AUXILIARY OPTIONS - “GA” (GAUGE ADAPTER) TWO PRESSURE GAUGES 100.00 3.94 1/4" NPT 216.87 8.54 AUXILIARY OPTIONS - “GM” (GAUGE MANIFOLD) 47.63 DOMED 1.88...
- Page 16 Tel.: +1 412 787 8803 India 560 066 Fax: +1 412 787 1944 Phone: +91 80 284 10 289 Fax: +91 80 284 10 286 All data subject to change without notice © ©02.2009 Flowserve Corporation. Flowserve and Kämmer are trademarks of Flowserve Corporation...
