Spare Parts Kits; Figure 58: Spare Parts Kits - Flowserve Logix 520MD+ User Instructions

21.2 Spare Parts Kits

Table 29: Spare Parts Kits
Ref. Description
Cover:
1 Yellow
1 Black
1 White
Board:
2 505+ Main
520MD+ Main
5 LCD
6 Pressure Sensor
7 Multi-Function Card (Slot1)
Multi-Function Card (Slot2)
8 V to I Card (Slot 1)
Pilot Relay Module:
10 Single Acting (Poppet)
11 Double or Single Acting (Spool)
12 Pneumatic Restrictor
Limit Switches:
13 Mechanical Switch*
14 Reed Switch
15 P&F SJ2-SN**
16 P&F SJ2-S1N**
17 P&F NJ2-V3-N**
18 P&F NBB2-V3-2N*
* Only available for general purpose (certification option 14).
** Only available for certification options 14 and 42.
NOTE: Multi-function cards and limit switches may be purchased
as upgrades and installed after the initial purchase of the
positioner. In this case, the positioner label must be modified
to reflect the change.
