10.2 Menu Overview

Status
Command (mA)
Command (%)
Position (%)
PS (Supply Pressure)*
PA (Port A Pressure)*
PB (Port B Pressure)*
Friction**
Actuation Ratio**
Pneumatic Leak**
Temperature
Valve Cycles
Valve Travel (%)
Card 1 Value
Card 2 Value
Alerts and Alarms
Current Alarms (Prioritized)
Event History
Last Event
2nd Event
3rd Event
*
*
*
32nd Event
Partial Stroke Test
Start
Last Result
Calibration
Stroke/Quick Calibration
Pressure Sensor Calibration
Friction Calibration
Triple Calibration
Command Input Calibration
Calibration Dates
Configuration
Positioner Tuning
Characterization
Pressure Control
Soft Limits & Cutoff
High Soft Limit
Low Soft Limit
Upper Position Cutoff
Lower Position Cutoff
Set Date & Time
User Preferences
All Units
Pressure Units
Force Units
Temperature Units
© Flowserve Corporation
User Instructions - Logix® 520MD+ Series Digital Positioner
Air Flow Units
Actuator Area Units
Date Format
Number Format
LCD Orientation
Burst Mode
ON/OFF
Positioner Revs
EC Major Rev
EC Minor Rev
EC Build Date and Time
Universal Rev
Hardware Rev
Factory Reset
Card 1 (or Card 2)
No Card: "No Card"
Multi-Function Card
Not Configured
Set as AO Card
Set as DO Card
Set as DI Card
Config/Cal
If Not Configured – "No Configuration Allowed"
If AO
If DO – "Use DTM"
If DI
Safety Discrete Output
Language
English
German
French
Spanish
Portuguese
Russian
Turkish
Italian
* Requires Advanced positioner upgrade.
** Requires Pro positioner upgrade.
26
FCD LGENIM0105-00
Set 0%
Set 100%
Set to No Action
Set to Trigger PST
Set to Command Override
Set Command Point
