3 SPECIFICATIONS

3.1

Input Signal

Table 1: Input Signal
Positioner Alone
or with
Multi-Function Card
Power Supply Two-wire, 4-20 mA
10,0 VDC plus line
losses.
Input Signal
Range
Compliance 10,0 VDC
Voltage
@ 20 mA
Effective 500
Resistance Typical
Maximum Supply
Voltage
Minimum
Required
Operating Current
Maximum Shut-
down Current
Communications
3.2

Air Supply

Table 2: Air Supply
Minimum Input 1,5 Bar (22 PSI)
Pressure
Maximum Input Single Acting Relay – 6,2 Bar (90 PSI)
Pressure
Double Acting Relay – 10,3 Bar (150 PSI)
(Set supply pressure as low as possible
for maximum relay life.)
Air Supply Quality The air supply must be free from moisture,
oil and dust by conforming to the ISA
7.0.01 standard. (A dew point at least 18
degrees Fahrenheit below ambient
temperature, particle size below five
microns—one micron recommended—and
oil content not to exceed one part per
million).
Operating Humidity 0 - 100% non-condensing
Acceptable Supply Air, sweet natural gas up to 5 bar, nitrogen
Gasses and CO2 are acceptable supply gasses.
Sour natural gas is not acceptable.
Air Consumption Single Acting Relay –
0.069 Nm³/h @ 1,5 bar
(0.041 SCFM @ 22 PSI)
0.082 Nm³/h @ 4,1 bar
(0.048 SCFM @ 60 PSI)
Double Acting Relay –
0.297 Nm³/h @ 1,5 bar
(0.175 SCFM @ 22 PSI)
0.637 Nm³/h @ 4,1 bar
(0.375 SCFM @ 60 PSI)
© Flowserve Corporation
User Instructions - Logix® 520MD+ Series Digital Positioner
Positioner with
Safety Discrete
Output Card
Two-wire, 4-20 mA
13,0 VDC plus line
losses.
4 - 20 mA (HART)
13,0 VDC
@ 20 mA
@ 20 mA 650 @ 20 mA
Typical
30 VDC
3,8 mA
3,6 mA
HART protocol
3.3

Pneumatic Output

Table 3: Pneumatic Output
Output Pressure 0 to 100% of air supply pressure.
Range
Output Air Capacity Single Acting Relay –
9.06 Nm³/h @ 1,5 bar
(5.33 SCFM @ 22 PSI)
20.8 Nm³/h @ 4,1 bar
(12.2 SCFM @ 60 PSI)
Double Acting Relay –
14.3 Nm³/h @ 1,5 bar
(8.44 SCFM @ 22 PSI)
30.6 Nm³/h @ 4,1 bar
(18.0 SCFM @ 60 PSI)
Primary Output Ports Single Acting Relay – Port B
(Port is pressurized in
Double Acting Relay – Port A
energized state. Port
is exhausted upon loss
of power.)
3.4

Stroke Output

Table 4: Stroke Output
Feedback shaft Min 15° , Max 90°
Rotation
40° recommended for linear applications.
3.5

Analog Output

Table 5: 4 to 20 mA Analog Output Specification
Potential Range of Rotation
Power Supply Range
Maximum Load Resistance
(ohms)
Current Signal Output
Linearity
Repeatability
Hysteresis
Operating Temperature
3.6

Safety Discrete Output

Table 6: Safety DO (Switch Function)
Power Supply Range
Maximum Load Resistance
(ohms)
Current Signal Output
Operating Temperature
3.7

Temperature

Table 7: Temperature
Operating -52° C* to 80° C (-61,6° to 176° F)
Temperature Range
Transport and Storage -52° C* to 80° C (-61,6° to 176° F)
Range
*Reduced performance at low temperatures.
7
Field Trial Version – Printed October 28, 2011
FCD LGENIM0105-00
40° to 95°
10.0 to 40 VDC, (24 VDC Typical)
(Supply Voltage - 10.0) / 0.02
4-20 mA
1.0% F.S.
0.25% F.S.
1.0% F.S.
-40 to 80° C (-40 to 176° F)
10.0 to 40 VDC, (24 VDC Typical)
TBD
TBD
-40 to 80° C (-40 to 176° F)
