Single-ended mode pin out

Pin Signal name
1 GND
2 CTR1 OUT
3 CTR1 CLK
4 CTR1 GATE
5 DOUT3
6 DOUT2
7 DOUT1
8 DOUT0
9 DIN3
10 DIN2
11 DIN1
12 DIN0
13 GND
14 -12 V
15 GND
16 +12 V
17 CH63 IN
18 CH62 IN
19 CH61 IN
20 CH60 IN
21 CH59 IN
22 CH58 IN
23 CH57 IN
24 CH56 IN
25 CH55 IN
26 CH54 IN
27 CH53 IN
28 CH52 IN
29 CH51 IN
30 CH50 IN
31 CH49 IN
32 CH48 IN
33 LLGND
34 CH47 IN
35 CH46 IN
36 CH45 IN
37 CH44 IN
38 CH43 IN
39 CH42 IN
40 CH41 IN
41 CH40 IN
42 CH39 IN
43 CH38 IN
44 CH37 IN
45 CH36 IN
46 CH35 IN
47 CH34 IN
48 CH33 IN
49 CH32 IN
50 GND
Table 22. 64-channel single-ended mode pin out
Pin Signal name
51 GND
52 EXTERNAL INTERRUPT
53 A/D EXTERNAL PACER
54 A/D STOP TRIGGER IN
55 A/D START TRIGGER IN
56 ANALOG TRIGGER IN
57 A/D PACER GATE
58 A/D PACER OUT
59 SSH OUT / D/A PACER OUT
60 EXTERNAL D/A TRIGGER/PACER GATE
61 D/A EXTERNAL PACER
62 PC +5 V
63 D/A OUT 1
64 D/A GND 1
65 D/A OUT 0
66 D/A GND 0
67 CH31 IN
68 CH30 IN
69 CH29 IN
70 CH28 IN
71 CH27 IN
72 CH26 IN
73 CH25 IN
74 CH24 IN
75 CH23 IN
76 CH22 IN
77 CH21 IN
78 CH20 IN
79 CH19 IN
80 CH18 IN
81 CH17 IN
82 CH16 IN
83 LLGND
84 CH15 IN
85 CH14 IN
86 CH13 IN
87 CH12 IN
88 CH11 IN
89 CH10 IN
90 CH9 IN
91 CH8 IN
92 CH7 IN
93 CH6 IN
94 CH5 IN
95 CH4 IN
96 CH3 IN
97 CH2 IN
98 CH1 IN
99 CH0 IN
100 LLGND
