PCI-DAS6013 and PCI-DAS6014 User's Guide

16-channel single-ended mode pin out

Pin Signal Name
1 LLGND
2 CH0 IN
3 CH8 IN
4 CH1 IN
5 CH9 IN
6 CH2 IN
7 CH10 IN
8 CH3 IN
9 CH11 IN
10 CH4 IN
11 CH12 IN
12 CH5 IN
13 CH13 IN
14 CH6 IN
15 CH14 IN
16 CH7 IN
17 CH15 IN
18 LLGND
19 n/c
20 n/c
21 n/c
22 n/c
23 n/c
24 n/c
25 n/c
26 n/c
27 n/c
28 n/c
29 n/c
30 n/c
31 n/c
32 n/c
33 n/c
34 n/c
35 AISENSE
36 D/A OUT 0*
37 D/A GND*
38 D/A OUT1*
39 PC +5 V
40 AUXOUT0 / D/A PACER OUT
41 AUXOUT1 / A/D PACER OUT
42 AUXOUT2 / SCANCLK
43 AUXIN0 / A/D CONVERT
44 n/c
45 AUXIN1 / A/D START TRIGGER
46 AUXIN2 / A/D STOP TRIGGER
47 AUXIN3 / D/A UPDATE
48 AUXIN4 / D/A START TRIGGER
49 AUXIN5 / A/D PACER GATE
50 GND
* = n/c on PCI-DAS6013
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Pin Signal Name
51 n/c
52 n/c
53 n/c
54 n/c
55 n/c
56 n/c
57 n/c
58 n/c
59 n/c
60 n/c
61 n/c
62 n/c
63 n/c
64 n/c
65 n/c
66 n/c
67 n/c
68 n/c
69 n/c
70 n/c
71 n/c
72 n/c
73 n/c
74 n/c
75 n/c
76 n/c
77 n/c
78 n/c
79 n/c
80 n/c
81 n/c
82 n/c
83 n/c
84 n/c
85 DIO0
86 DIO1
87 DIO2
88 DIO3
89 DIO4
90 DIO5
91 DIO6
92 DIO7
93 CTR1 CLK
94 CTR1 GATE
95 CTR1 OUT
96 GND
97 CTR2 CLK
98 CTR2 GATE
99 CTR2 OUT
100 GND
40
