Differential mode pin out

Pin Signal Name
1 GND
2 CTR1 OUT
3 CTR1 CLK
4 CTR1 GATE
5 DOUT3
6 DOUT2
7 DOUT1
8 DOUT0
9 DIN3
10 DIN2
11 DIN1
12 DIN0
13 GND
14 -12 V
15 GND
16 +12 V
17 CH31 IN LO
18 CH30 IN LO
19 CH29 IN LO
20 CH28 IN LO
21 CH27 IN LO
22 CH26 IN LO
23 CH25 IN LO
24 CH24 IN LO
25 CH23 IN LO
26 CH22 IN LO
27 CH21 IN LO
28 CH20 IN LO
29 CH19 IN LO
30 CH18 IN LO
31 CH17 IN LO
32 CH16 IN LO
33 LLGND
34 CH15 IN LO
35 CH14 IN LO
36 CH13 IN LO
37 CH12 IN LO
38 CH11 IN LO
39 CH10 IN LO
40 CH9 IN LO
41 CH8 IN LO
42 CH7 IN LO
43 CH6 IN LO
44 CH5 IN LO
45 CH4 IN LO
46 CH3 IN LO
47 CH2 IN LO
48 CH1 IN LO
49 CH0 IN LO
50 GND
Table 21. 32-channel differential mode pin out
Pin Signal Name
51 GND
52 EXTERNAL INTERRUPT
53 A/D EXTERNAL PACER
54 A/D STOP TRIGGER IN
55 A/D START TRIGGER IN
56 ANALOG TRIGGER IN
57 A/D PACER GATE
58 A/D PACER OUT
59 SSH OUT / D/A PACER OUT
60 EXTERNAL D/A TRIGGER/PACER GATE
61 D/A EXTERNAL PACER
62 PC +5 V
63 D/A OUT 1
64 D/A GND 1
65 D/A OUT 0
66 D/A GND 0
67 CH31 IN HI
68 CH30 IN HI
69 CH29 IN HI
70 CH28 IN HI
71 CH27 IN HI
72 CH26 IN HI
73 CH25 IN HI
74 CH24 IN HI
75 CH23 IN HI
76 CH22 IN HI
77 CH21 IN HI
78 CH20 IN HI
79 CH19 IN HI
80 CH18 IN HI
81 CH17 IN HI
82 CH16 IN HI
83 LLGND
84 CH15 IN HI
85 CH14 IN HI
86 CH13 IN HI
87 CH12 IN HI
88 CH11 IN HI
89 CH10 IN HI
90 CH9 IN HI
91 CH8 IN HI
92 CH7 IN HI
93 CH6 IN HI
94 CH5 IN HI
95 CH4 IN HI
96 CH3 IN HI
97 CH2 IN HI
98 CH1 IN HI
99 CH0 IN HI
100 LLGND
