PCI-DAS64/M1/16 User's Guide

Digital input/output connector and pin out

Connector type
Connector compatibility
Compatible cable
Compatible accessory products
Pin Signal name
1 NC
3 NC
5 FIRSTPORTB Bit 7
7 FIRSTPORTB Bit 6
9 FIRSTPORTB Bit 5
11 FIRSTPORTB Bit 4
13 FIRSTPORTB Bit 3
15 FIRSTPORTB Bit 2
17 FIRSTPORTB Bit 1
19 FIRSTPORTB Bit 0
21 DIG GND
23 NC
25 DIG GND
27 NC
29 DIG GND
31 NC
33 DIG GND
35 PC +5 V
37 DIG GND
39 NC
Table 23. Digital I/O connector specifications
40-pin header
Translates to standard CIO-DIO24 type using BP40-37
C40FF-2
CIO-MINI40
Table 24. Digital I/O connector pin out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
6-13
Signal name
PC +5 V
DIG GND
FIRSTPORTC Bit 7
FIRSTPORTC Bit 6
FIRSTPORTC Bit 5
FIRSTPORTC Bit 4
FIRSTPORTC Bit 3
FIRSTPORTC Bit 2
FIRSTPORTC Bit 1
FIRSTPORTC Bit 0
FIRSTPORTA Bit 7
FIRSTPORTA Bit 6
FIRSTPORTA Bit 5
FIRSTPORTA Bit 4
FIRSTPORTA Bit 3
FIRSTPORTA Bit 2
FIRSTPORTA Bit 1
FIRSTPORTA Bit 0
NC
NC
