Reset Modes: a Brief Summary
The MLC Plus controllers offer the following reset modes:
Use Factory Firmware:
•
Project Recovery:
•
Toggle DHCP:
•
Reset All IP Settings:
•
Reset to Factory Defaults: Press and hold the Reset button for 9 seconds. After the Reset LED blinks three times,
•
For detailed information on each mode and its use, see the MLC Plus 50/100/200 Series User Guide at www.extron.com.
About Global Configurator (with GC Professional and GC Plus Modes)
What the Software Does
Global Configurator Professional or Plus is the software tool for network setup and configuration of a MediaLink Plus controller.
Global Configurator:
Loads device drivers for controlling and monitoring the status of devices within the AV system.
•
Creates the configuration containing all the settings for the controller and the products with which it interacts in the AV
•
system.
Generates a user interface called GlobalViewer that is uploaded to the MLC (a GlobalViewer host device) along with the
•
completed configuration and can be accessed as a Web page. Using GlobalViewer, users can monitor the MLC Plus.
Extron Control applications can also be used with the MLC Plus to permit remote control of the unit and, by extension, the Extron
and third-party equipment (such as switchers, projectors, displays, computer monitors, and DVD players) that the MLC Plus is
configured to control.
Resources
Obtaining Control Drivers
Extron provides an extensive selection
of device drivers available on the Extron
website. If the system requires a control
driver that is not already available, you can
request a new serial (RS-232), IR, or Ethernet
driver from Extron.
Press and hold the Reset button while applying power to the unit. Use this mode to temporarily
revert to factory firmware in the event of a firmware failure.
See the MLC Plus 50/100/200 Series User Guide for instructions. Use this mode to recover the
project in the event of a lost user name and password.
Press the Reset button five times (consecutively). Release the button. Do not press the button
within 3 seconds following the fifth press. Use this mode to enable or disable the DHCP client
for the LAN port.
The Reset LED blinks 6 times if the DHCP client is enabled.
•
The Reset LED blinks 3 times if the DHCP client is disabled.
•
NOTES:
DHCP toggle mode is supported on firmware version 2.03 or higher.
•
By default DHCP is off and the unit uses a static IP address.
•
When you disable DHCP, the unit uses the factory default IP address
•
(192.168.254.250).
Press and hold the Reset button for 6 seconds. After the Reset LED blinks twice, release and
momentarily press and release the Reset button within 1 second. Use this mode to reset all
network settings to factory default values without affecting user-loaded files.
release and momentarily press and release the Reset button within 1 second. Use this mode to
return the controller to factory default settings.
Obtaining Instructions, Information, and Assistance
A checklist of basic setup steps is provided in this guide. For additional
information see the help files and the MLC Plus 50/100/200 Series User
Guide, available at www.extron.com.
If you have questions during installation and setup, call the
Sales & Technical Support Hotline
Support Hotline (1.800.633.9877).
Extron S3
or the Extron S3 Control Systems
