WC Pro 150 OCS • Setup Guide
IMPORTANT NOTE:
Go to www.extron.com
product to the power source.
This guide provides basic instructions for an
experienced technician to install the WC Pro 150 OCS
Workspace Automation Controller.
The WC Pro 150 OCS Workspace Automation
Controller is a small and medium space, PoE powered
integrated control processor with an occupancy sensor
used to detect occupancy using Passive Infrared (PIR)
and an acoustic sensor, when people walk into a room.
Unique status LED indicators for each sensor are
used for ease of installation as well as intuitive setup.
Control options allow for control of virtually any display
via Ethernet, bidirectional RS-232, IR, or CEC.
There are three ways the WC Pro 150 OCS can
be configured. First, out of box the workspace
controller is preconfigured for CEC control of display (see the
Second, simple web configuration can be done via the internal web page for basic power on and off automation of display and projector
devices (see the WC Pro 150 OCS User Guide available at www.extron.com). Third, advanced configuration can be done using Global
Configurator Professional (GC Professional) or Global Configurator Plus (GC Plus). For configuration with Global Configurator Professional
(GC Professional) or Global Configurator Plus (GC Plus) the LinkLicense for WC Pro Control Processor is required. Global Configurator and
other useful software applications are available at www.extron.com.
Port Expansion Interface Connections
Figure 1. WC Pro 150 OCS Port Expansion Interface Connections
ATTENTION:
•
Power over Ethernet (PoE) is intended for indoor use only. It is to be connected only to networks or circuits that are not routed to
the outside plant or building.
•
L'alimentation via Ethernet (PoE) est destinée à une utilisation en intérieur uniquement. Elle doit être connectée seulement à des
réseaux ou des circuits qui ne sont pas routés au réseau ou au bâtiment extérieur.
•
The WC Pro 150 OCS is intended for connection to a Power over Ethernet circuit for intra-building use only and are considered to
be part of a Network Environment 0 per IEC TR62101.
•
Le WC Pro 150 OCS est conçu pour une connexion à un circuit PoE pour une utilisation intérieure seulement et est considéré
comme faisant partie d'un environnement réseau 0 par IEC TR62101.
RS-232 COM control port — Insert a 3-pole captive screw connector for bidirectional RS-232 control (see
B
COM (serial)
on page 2 for wiring information). The default protocol is:
• •
Baud: 9600
IR control port — Insert a 2-pole captive screw connector for unidirectional IR control (see
C
wiring information).
Digital I/O control port — Insert a 3-pole captive screw connector for Digital Input and Output 1 and 2 (see
D
and Output
on page 3 for wiring information).
for the complete user guide, installation instructions, and specifications before connecting the
D D D
C C C
B B B
A A A
•
Data bits: 8 Stop bit: 1
CEC Compatibility Chart) and occupancy status on Digital output 2.
LAN (Ethernet) and PoE port and LEDs — Insert a network
A
cable into the RJ-45 female connector for network connectivity
and to power the workspace controller (see
Power — LAN (Ethernet) and PoE
instructions).
• •
Parity: None
on page 3 for wiring
Control, Bidirectional —
Flow Control: None
Control — IR Output on page 2 for
Control — Digital Input
Control and
