Summary of Contents for Extron electronics WC Pro 150 OCS
- Page 1 WC Pro 150 OCS Workspace Automation Controller with Occupancy Sensor User Guide Workspace Automation Controllers 68-3258-01, Rev. A 01 25...
-
Page 2: Safety Instructions
Safety Instructions... - Page 3 Copyright © 2025 Extron. All rights reserved. www.extron.com Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks ( ® ), registered service marks ( ), and trademarks ( ) are the property of RGB Systems, Inc. or Extron (see the Terms of Use page at www.extron.com): current list of trademarks on the...
-
Page 4: Fcc Class A Notice
FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Software Commands
Conventions Used in this Guide Notifications The following notifications are used in this guide: WARNING: Potential risk of severe injury or death. AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. ATTENTION: • Risk of property damage. • Risque de dommages matériels. NOTE: A note draws attention to important information. -
Page 7: Table Of Contents
Pre-Configured features ..........................4 Room Occupancy Status on the Digital Output Port 2 ...................4 Configuration of the WC Pro 150 OCS with the Internal Web Page..............4 Advanced Configuration of the WC Pro 150 OCS with GCP ................4 What the Software Does ..........................5 PC System Requirements ..........................5... - Page 8 Activity Statistics ..............................44 Firmware Updates ..........................45 Determining the Firmware Version ........................45 Using Global Configurator and Toolbelt .......................45 Using a Browser ............................45 Updating the Firmware ............................45 Locating and Downloading the Firmware .....................46 Installing Firmware ............................46 WC Pro 150 OCS • Contents viii...
-
Page 9: Introduction
Conventions Used in This Guide Throughout this guide the WC Pro 150 OCS is also referred to as the “WC”, “WC Pro”, “sensor”, or “controller”. Global Configurator software is referred to as “GC,” which can be run in Global Configurator Professional mode (“GC Professional”) or Global Configurator Plus mode (“GC Plus”). -
Page 10: Features
DNS, HTTP, HTTPS, ICMP, NTP, SFTP, SMTP, SNMP, SSH, TCP/IP, and UDP/IP. • Network connection — The WC Pro 150 OCS supports 10/100Base-T Ethernet communication. • Remote equipment management — The IP Link Pro connection via the LAN port on the WC Pro allows you to remotely manage, monitor, and control several Ethernet-enabled products such as projectors, cameras, video conferencing equipment, switchers, and other AV equipment. -
Page 11: Application Diagrams
Videobar (Camera / Mic / Speakers) RS-232 Ethernet/PoE HDMI Ethernet MTR Compute MTR Touchscreen Module Console Figure 1. WC Pro 150 OCS Application Diagram Laptop Flat Panel Display MODEL 80 Laptop HDMI HDMI Extron Extron FLAT PANEL NBP 1200C WC Pro 150 OCS... -
Page 12: Pre-Configured Wc Pro 150 Ocs
This factory configuration can be modified using the Internal Web Page. If the WC Pro 150 OCS is reset, the device reverts back to the factory out-of-box default web configuration with CEC display control. -
Page 13: What The Software Does
When the Extron LinkLicense for User Interface is enabled on the controller, Extron Control for web, iOS, or Android can be used with the WC Pro 150 OCS to permit remote control of the unit and, by extension, the Extron and third-party equipment (such as switchers, projectors, displays, computer monitors, and DVD players) that the WC Pro 150 OCS is configured to control. -
Page 14: Installation And Operation
Use the following checklist to prepare for the installation. 1. Download and install the latest version of the following: NOTE: If using the WC Pro 150 OCS with the out of the box configuration or the internal web pages for Installation Step 2: Prepare the Installation Site configuration, skip to on page 7. -
Page 15: Installation Step 2: Prepare The Installation Site
Control and power — LAN (Ethernet) and PoE LAN (Ethernet) and PoE port and LEDs — Connect the WC Pro 150 OCS to an Ethernet network. Plug a cable from the LAN RJ-45 socket to a network switch, hub, router, or PC connected to a LAN or the Internet. - Page 16 Network Environment 0 per IEC TR62101. • Le WC Pro 150 OCS est conçu pour une connexion à un circuit PoE pour une utilisation intérieure seulement et est considéré comme faisant partie d’un environnement réseau 0 par IEC TR62101.
- Page 17 Extron device driver communication sheet, included with the drivers. NOTE: Maximum distances between the WC Pro 150 OCS and the device being controlled may vary up to 200 feet (61 m). Factors such as cable gauge, baud rates, environment, and output levels (from the WC Pro 150 OCS and the device being controlled) all affect transmission distance.
- Page 18 • Monitor or trigger events and functions (toggle relays, issue commands, send e-mail), once con gured. If the WC Pro 150 OCS is operating with the out of the • Trigger LEDs, incandescent lights, or other devices that accept a TTL signal.
- Page 19 When the port is set to an On state, (the switch 1 circuit is closed), the I/O pin is connected to ground. Output voltage is less than 0.5 volts. • When the port is set to the Off state (the switch 1 circuit is open), the output pin floats (is not connected). WC Pro 150 OCS • Installation and Operation...
- Page 20 • The connected LED is off when the port and switch 1 are open. • The connected LED is on when the port and switch 1 are closed. WC Pro 150 OCS • Installation and Operation...
- Page 21 +5.0 V 2k ohms DTP T UWP 4K 232 D SW 2 Digital Voltage SW 1 Protection Figure 12. Digital Output Application With Pull-up: Contact Closure Input Selection on a Connected Device WC Pro 150 OCS • Installation and Operation...
-
Page 22: Panel Features
HDMI/CEC port — Connect an AV device to the HDMI/CEC output port. If the CEC-compliant display supports CEC control, the WC can automatically turn display power on or off based on whether occupancy is detected. WC Pro 150 OCS • Installation and Operation... - Page 23 WC Pro 150 OCS ships with basic CEC control built into the default configuration. Basic CEC controls in that configuration work out of the box, but can be further customized using Global Configurator software.
-
Page 24: Installation Step 4: Set Up Network Communication
MAC address label on the device). Installation Step 5: Configure the WC Pro 150 OCS The WC Pro 150 OCS is shipped preconfigured for CEC functionality with the digital output port 2 following the occupancy status. The WC Pro also has internal web pages to configure and customize the functionality (see... -
Page 25: Installation Step 6: Test And Troubleshoot
• Do not use any other screw in the threaded hole in the mounting post of the WC Pro 150 OCS. The provided screw allows mobility of the controller without loosening the connection. - Page 26 4. Connect power to the source to all devices in Figure 16. Mounting Bracket Dimensions (Side View) the system. D I/O LAN/PoE NOTE: The WC Pro 150 OCS is powered through the LAN port, so be sure to make that connection. WC Pro 150 OCS • Installation and Operation...
-
Page 27: Resetting The Unit
If you want to use the incompatibility firmware version with which the unit shipped, issues arise you must upload that version again (see the with Global Configurator Help File or Toolbelt Help File userloaded for instructions). firmware. WC Pro 150 OCS • Installation and Operation... - Page 28 By default, DHCP is off and the unit uses a static IP address. • When DHCP is disabled, the unit uses the factory default IP address (192.168.254.250), or the previously stored static IP address if it was not at default. WC Pro 150 OCS • Installation and Operation...
-
Page 29: Sensor Coverage
Sensor Coverage The WC PRO 150 OCS covers a a maximum of 20 feet x 20 feet or up to 400 square feet room with the controller mounted below a display (4 feet [1.22 m] from the floor). This is the top field of view of the sensor coverage. The two colors indicate the individual left and right PIR sensors coverage that overlap in the middle. - Page 30 WC Pro 150 OCS • Installation and Operation...
-
Page 31: Internal Web Page Configuration
Internal Web Page Configuration The WC Pro 150 OCS workspace automation controller features internal web pages. Configure and monitor certain settings of the WC Pro device via a LAN connection. Use a web browser to view the pages on a PC or any other mobile device connected to the device LAN port or the same network. -
Page 32: Configuration With The Web Pages
Configuration with the Web Pages The WC Pro 150 OCS internal web page opens to the Device Utilities page (see figure 20) that provides a read-only view of the general Device Details and Unit Status of the WC Pro 150 OCS, with some configuration panels, pages, and buttons for the date and time, network connections, passwords, firmware update, sensor settings and display control, backup, restore, reboot, and reset the unit. -
Page 33: Device Detail Panel
Click RESET to continue or CANCEL to quit the reset. Resets all settings and deletes all user loaded content on internal storage, while retaining TCP/IP settings. Reverts back to the default factory configuration and functionality WC Pro 150 OCS • Internal Web Page Configuration... -
Page 34: Network Panel
24), change the device name (hostname) and edit the IP address, subnet mask, gateway address, DNS server, and search domain name for the WC Pro 150 OCS, or turn DHCP On and Off. NOTE: The user can change the name and set the IP addresses all at once before clicking SAVE at the end of the process. -
Page 35: Date And Time Panel
NTP Server. 4. When finished editing, click SAVE to confirm your changes or CANCEL to close the window without making changes. Figure 23. Sync to NTP Servers Mode WC Pro 150 OCS • Internal Web Page Configuration... -
Page 36: Roles And Permissions Panel
5. When finished, click CHANGE to set the passwords. To close the window without saving a password, click CANCEL. NOTE: Passwords can be changed but they cannot be removed entirely. The WC Pro 150 OCS must have passwords at all times. These fields cannot be blank. -
Page 37: Firmware Panel
24) displays the current firmware version, the web version (version of the internal web pages) and the date it was last updated. Update the firmware on the WC Pro 150 OCS from this panel (see Software/Firmware Installation on page 48 to download the firmware files). To update firmware: 1. -
Page 38: Display Control Page
Communication Sheets are available for download on every CEC, Ethernet, and serial driver (not IR) for general assistance with the display device setup and information. Note: IR drivers do not have communication sheets. WC Pro 150 OCS • Internal Web Page Configuration... -
Page 39: Selecting A Driver
3. Click CONFIRM to complete the process or CANCEL to close the dialog without adding the driver. 4. A confirmation message banner posts at the top of the driver page with a message that the driver was successfully added. WC Pro 150 OCS • Internal Web Page Configuration... -
Page 40: Editing A Driver
Power Settings page Configure the WC Pro 150 OCS to enable display power on or off automation based on the room occupancy status detected from the integrated occupancy sensors. Toggle the switches to automate powering of the display on and off based on the room occupancy. -
Page 41: Schedules Page
1. Click the trash can icon from the line of the desired schedule to delete. A dialog opens to confirm the deletion of the schedule. 2. Click DELETE to delete the schedule. To close the window without deleting Figure 28. Schedules Pane the schedule, click CANCEL. WC Pro 150 OCS • Internal Web Page Configuration... -
Page 42: Sensor Page
NOTE: Extron has selected default values determined ideal settings for most typical applications. We recommend using the WC Pro 150 OCS in the default settings when beginning the setup and testing. If needed, make slight adjustments at a time from the default sensitivity settings. -
Page 43: Inactivity Timer
Dual Technology Mode Undetected Once both motion and acoustic is detected, the check marks turn green and the room occupancy status changes to Occupied. Figure 31. Dual Technology Mode with Single Sensor Type Detected WC Pro 150 OCS • Internal Web Page Configuration... -
Page 44: About The Wc Pro 150 Ocs
24) to open the About dialog box to view general information ¢ about the WC Pro 150 OCS, such as the firmware version, copyright, part number, licenses, patents and web page version. Click on the View the End User License Agreement link to view the user license. -
Page 45: Advanced Software Configuration
NOTE: See the diagram within Control and power — LAN (Ethernet) and PoE on page 7 for the default login credentials. WC Pro 150 OCS • Advanced Software Configuration... -
Page 46: Basic Setup Steps: A Guide To This Section And Other Resources
Import GUI layouts and con gure the touchpanels or other interfaces. Save the project. Build and upload the con guration to the control processor. Test the system, make adjustments, nalize con guration. Figure 33. Overall Configuration Steps WC Pro 150 OCS • Advanced Software Configuration... -
Page 47: Downloading The Software And Getting Started
To download a single driver rather than the package, click on the appropriate link in the row for the product desired to control to download the driver or to download the communication sheet. The communication sheet provides details helpful for working with the product and its control driver. WC Pro 150 OCS • Advanced Software Configuration... -
Page 48: Obtaining Control Drivers
Using GC: Helpful Tips Resources and Notes • The WC Pro 150 OCS Setup Guide ships with the units. It includes a quick reference to the front and rear panel features, and covers basic hardware installation. • Panel Features... -
Page 49: Troubleshooting
Verify input voltage at the digital input port does not exceed 24 VDC. If you are still experiencing problems, call the Extron S3 Sales & Technical Support Hotline or the Extron S3 Control Systems Support Hotline (1.800.633.9877). WC Pro 150 OCS • Advanced Software Configuration... -
Page 50: Reference Information
File Types: a Key to Extron-Specific File Names • SNMP • Activity Statistics Full product specifications are available via the WC Pro 150 OCS product pages at www.extron.com. UL Guidelines The following Underwriters Laboratories (UL) guidelines pertain to the WC Pro 150 OCS: CAUTION: •... -
Page 51: Best Practices For Cleaning Your Extron Products
.eir — These are IR driver files containing infrared commands for both web configuration and GCP. There is a separate .eir file for each device the WC Pro 150 OCS controls via infrared communication. Via Global Configurator, these files can be imported and associated with an IR port on a controller. -
Page 52: Snmp
Activity Statistics WC Pro 150 OCS logs its sensor activity status and room occupancy status events (not head counts). These logs can be retrieved using the Toolbelt > Logs tab and saved as a text file. The *.txt file can be imported into tools like Microsoft Power BI or Excel to create statistics and analysis on room usage. -
Page 53: Firmware Updates
1. Start a browser program. 2. Type the IP address of the WC Pro 150 OCS into the address field of the browser and log on to the internal web page or to the optional GlobalViewer web page stored in the WC Pro (see the Global Configurator Help File for details). -
Page 54: Locating And Downloading The Firmware
PC in C:\Program Files (x86)\Extron\Firmware\ WC Pro 150 OCS within a folder specific to that version. 3. Write down the firmware filename and location for later use. The filename ends in .eff such as 49-622-50-x.xx.xxxx-yyyy.eff where x.xx.xxxx is the version number. -
Page 55: Extron Warranty
Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
