Optional accessories

Digital scales

The Euro-150TE/TX Flexy allows for the connection of digital electronic scales with an RS-232 interface. You
can also use them without a connection to the cash register. We supply scales with official certification and
on request with a connecting cable.
Figure 6.1 - Digital scales
Ask your authorized Euro-150TE/TX Flexy dealer about the supply and connection of an electronic scale..

Barcode scanners

The Euro-150TE/TX Flexy cash register comes equipped with an interface for connecting a barcode scanner.
If you decide to use a barcode scanner, this section offers some recommendations for how to choose one.
In each case we recommend buying and connecting a scanner with the help of your local Euro-150TE/TX
Flexy dealer.
Barcode scanner connects to the cash register via a built-in serial RS-232 interface. The barcode scanner
must be equipped with the same interface. For a scanner connection, the cash register offers a single di-
rection +5V adapter for the port COM1 (Port1 optional accessory); if you are using the COM2 (Port2) and
COM3 (Port3) ports to connect the scanner, you must use an external power supply. Prior to connecting a
scanner it is necessary to correctly program both the scanner and the cash register. We recommend using
a scanner with its own power supply.
We recommend Metrologic scanners for working with the cash register. Ask your Euro-150TE/TX Flexy
dealer for more information.

MS-5145 Eclipse

A manual scanner with no holder, which scans upon the pressing of a trigger. The method of scanning is
the LED 650 nm ± 5 nm, scanner speed is 72 lines/s, scanning distance is 140 mm and the minimal width
of the bar is 0.102 mm. RS-232 interface.
Figure 6.2 - MS-5145 Eclipse scanner

Metrologic Orbit MS-7120

An omnidirectional, very fast, laser barcode scanner. The scanner uses an LED 650 nm ± 5 nm for scanning,
the speed of the omnidirectional scanning is 1200 lines/s (20 scanning lines), scanning grid of 5 x 4 parallel
lines, scanning distance is 203 mm and the minimum bar width of 0.13 mm.
76
