Mechanical Installation

3 Mechanical Installation

3.1 Unpacking

3.1.1 Items Supplied
•
Check the packaging and the frequency converter
visually for damage caused by inappropriate
handling during shipment. File any claim for
damage with the carrier. Retain damaged parts
for clarification.
•
Make sure the items supplied and the
information on the nameplate correspond to the
order confirmation.
VLT
R
HVAC Drive
www.danfoss.com
1
T/C: FC-102P3K0T4Z55H1UGCXXXSXXXXAXBXCXXXXDX
2
P/N: 131U3930 S/N: 010102G290
3
3.0kW(400V) / 4.0HP(460V)
4
IN: 3x380-480V 50/60Hz 6.5/5.7A
5
OUT: 3x0-Vin 0-590Hz 7.2/6.3A
6
Type 12 / IP55 Tamb.45 C/113 F o
* 1 3 1 U 3 9 3 0 0 1 0 1 0 2 G 2 9 0 *
Listed 76X1 E134261 Ind. Contr. Eq.
CAUTION:
See manual for special condition/mains fuse
9
voir manual de conditions speclales/fusibles
WARNING:
Stored charge, wait 4 min.
`
Charge residuelle, attendez 4 min.
Illustration 3.1 Product Nameplate (Example)
®
VLT HVAC Drive Operating Instructions
10
8
7
o
MADE IN DENMARK
`
MG11AJ02 - Rev. 2013-07-31
1 Type code
2 Order number
3 Power rating
Input voltage, frequency and current (at low/high
4
voltages)
Output voltage, frequency and current (at low/high
5
voltages)
6 Enclosure type and IP rating
7 Maximum ambient temperature
8 Certifications
9 Discharge time (Warning)
10 Serial number
Table 3.1 Legend to Illustration 3.1
NOTICE
Do not remove the nameplate from the
frequency converter (loss of warranty).
3.1.2 Storage
Ensure that requirements for storage are fulfilled. Refer to
8.4 Ambient Conditions for further details.
