TAB 4 - LPF Misc

Stereo Split Resonance Drive Key>LPF Freq
0
Stereo Split
VCF ADSR VCF Env Amt LP Filter LPF Misc
—This offsets the filter cutoff frequency between
Stereo Split: +82... -82
the Prophet X's stereo filters. Turning the knob clockwise simultaneously
increases the cutoff frequency in the left channel and reduces the cutoff
frequency in the right channel. Conversely, turning the knob counter-
clockwise simultaneously increases the cutoff frequency in the right
channel and reduces the cutoff frequency in the left channel. This can be
useful for creating additional depth in the stereo field. This control has no
effect in 16-voice mode since the signal path is monophonic.
36 Filter Dave Smith Instruments
