When Key Follow is on, the oscillator tracks the
Key Follow: Off, On—
keyboard or note data received via MIDI. When off, the oscillator plays
at its base frequency setting, though the pitch may be affected by modu-
lation from other sources.

TAB 2 Osc Shape

Shape Shape Mod Sync Wave Reset
Pulse 0
SHAPE SHAPE MOD SYNC WAVE RESET
Osc1 Tune Osc1 Shape Osc1 Misc Osc Select
This selects the waveshape
Shape: Sine, Sawtooth, Pulse, Super Saw —
generated by the oscillator. You can also turn the sound of the oscillator
off by selecting no waveshape.
-64...+63 – Changes the "pulse" width of the selected
Shape Mod:
waveform, which modifies its harmonic content and timbre. To generate a
square wave when is selected as the waveform, set this parameter to 0.
pulse
-64 0 63
Oscillator pulse width (square wave)
—Turns Oscillator 1 hard sync on. Sync forces Oscillator 1
Sync: Off, On
(the slave) to restart its cycle every time Oscillator 2 (the master) starts
a cycle. This provides a way to create more complex, harmonically rich
shapes from simple waveforms—especially when the frequency of Oscil-
lator 1 is set to a different interval than Oscillator 2.
26 Oscillators Dave Smith Instruments
