Transmitted Controller Messages
Status Second
1011 nnnn 0000 0001
1011 nnnn 0000 0010
1011 nnnn 0000 0100
1011 nnnn 0000 1101
1011 nnnn 0000 0111
1011 nnnn 0100 1010
1011 nnnn 0010 0000
1011 nnnn 0100 0000
1011 nnnn 0000 0111
See sections that follow for additional Continuous Controller (CC) and
Non-Registered Parameter Number (NRPN) messages transmitted.
Prophet X User's Guide
Third Description
0vvvvvvv Mod Wheel
0vvvvvvv Breath Controller: When assigned to Pedal/CV
0vvvvvvv Foot Controller: When assigned to Pedal/CV
0vvvvvvv Expression: When assigned to Pedal/CV
0vvvvvvv Volume: When assigned to Pedal/CV
0vvvvvvv Brightness: Assigned to Pedal/CV
0vvvvvvv Bank Select: 0 - 9
0vvvvvvv Damper pedal: Sends 0 if off, 0111 1111 when on
0vvvvvvv Volume knob
Appendix E: MIDI Implementation 143
